2013 Hot Selling Quarry Stone Drilling Machine

Zhengzhou Unique Industrial Equipment Co., Ltd.
2013 Hot Selling Quarry Stone Drilling Machine thumbnail-1
2013 Hot Selling Quarry Stone Drilling Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drilling Rig
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or other China main port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Rotary Drilling Rig
Power Type Diesel
Model Number KY100
Usage Other, drilling borehole for quarry, mining and construction
Dimension(L*W*H) 4100x2030x2020mm
Weight 3.2t
Certification ISO
Warranty 15 months
After-sales Service Provided Engineers available to service machinery overseas





It is widely used in quarry, railway, road, water and electricity, open-pit mines and construction work site to do deep or medium-deep rock hole drilling operations. Woring with the air compressor and the impactor(DTH hammer), it can drill horizontal, vertical, inclined blast hole, pre-hole and anchor bolt holes.



Specifications of Crawler Drill KY100

Rock Rigidity: f=6-20

Dia. of hole: 80-105 mm

Optimum Drilling Depth: 20 m

Working Pressure: 0.5-0.7 Mpa

Air Consumption: ≥10m3/min.

Rotation Speed: 0-65 rpm

Torque: 983 N•m

Lift power: 15KN

Rod specification: 60x2000 mm

Gradeability: 30°

Ground Clearance: 254 mm

Walking Speed: 2.0 Km/h

Dimensions: 4100x2030x2020mm

Weight: 3200 kg

Drive System: YC2108 Engine (33Kw, 2200r/min)

Recommended Compressor: LGCY12/10





Model: LGCY12/10



Capacity: 12 m3/min.(424cfm)



Working Pressure: 1.0 Mpa (145psig)



Fluid capacity: 35L



Compression stage: single



Diesel Engine: YC6B150Z-K20,110KW(150HP)



Dimensions: 3970x1940x2350 mm



Total Weight: 2380 kg



2013 hot selling quarry stone drilling machine



2013 hot selling quarry stone drilling machine









2013 hot selling quarry stone drilling machine



2013 hot selling quarry stone drilling machine
