Specifications
KG940A Portable Driling Rig for Marble1.Quick lifting valve group
2. Commins engine
3.Rotation speed:105r/min
KG940A Portable Driling Rig for Marble
High Wind Pressure Open-Air New Arrivel Portable Driling Rig for Marble .
Advantages of KG940A New Arrivel Portable Driling Rig for Marble
1. Safe and Stable Travelling System
2. Powerful and reliable engine
3. New Drilling boom
Specification of KG940A New Arrivel Portable Driling Rig for Marble
|
Model
Specification |
KG940A |
Improved by: |
KY140 |
Rock hardness |
F=6-20 |
Hole diameter(mm) |
105-165 |
Drill depth(m) |
25 |
Pressure (Mpa) |
1.0-2.4 |
Air consumption (M3/min) |
12-24 |
Rotating speed (Km/h) |
0-63 |
Lifting capacity (KN) |
20 |
Drill rod specification(mm) |
76×3000 /89×3000 |
Gradeability |
30° |
|
Ground clearance(mm) |
320 |
Walking speed (km/h) |
2.0 |
Drill arm rising angles (°) |
-15~+50 |
Drill arm swing angle (°) |
±45 |
Carriage swing angle(°) |
±50 |
Carriage pitch angle (°) |
180 |
Carriage Compensation(mm) |
1200 |
|
Overall Dimension (L*W*H)(mm) |
5850×2250 ×2020 |
Total Weight (Kg) |
5500 |
Note: |
Pneumatic -hydraulic |
Comparsion Between KY140 and KG940 New Arrivel Portable Driling Rig for Marble
|
KY140 |
KG 940A |
Advantages |
Drill boom |
|
New type drills boom |
Simultaneously drill horizontal hole and vertical hole |
Hydraulic system |
28.2 pump |
32 pump,big diameters, new type valve groups, new type joint. |
Flow is increased, resistance is reduced. |
Carriage parts |
Channel Steel Carriage |
thick plate reinforced carriage, pressing plate |
Rigidity is increased, Abrasion is reduced |
Air control system |
Ball valve |
side valve type c oncussion relief valve |
Easy operation |
Rotation speed |
62 r/min(1700) |
71 r/min (diesel engine 1700r/min) 100 r/min(diesel engine 2200 r/min) |
Improved by 14% |
Advance speed |
530mm/s |
580mm/s |
Improved by 10% |
Mobile Screw Air Compressor
Model |
Work pressure |
Capacity |
Diesel engine (hp) |
Weight |
Dimension |
LGCY-12/10 |
1.0 |
12 |
YuChai |
3500
|
3600*1900*2200
|
LGCY-13/13 |
1.3 |
13 |
Cummins |
||
LGCY-15/13 |
1.5 |
15 |
YuChai |
||
LGCY-18/17 |
1.7 |
17 |
Cummins |
OUR PRODUCT SCOPE: |
Mobile Crusher: portable jaw crusher, portable impact crusher, portable cone crusher, portable construction waste crushing plant |
Stone Crusher: jaw crusher, impact crusher, Symons cone crusher, spring cone crusher, sand making machine, hammer crusher, ball mill etc. |
Auxiliary equipment: vibrating feeder, vibrating screen, belt conveyor, crawler rock drill |
Zhengzhou Unique Industrial Equipment Co., Ltd,a reliable and professional supplier of Portable Driling Rig for Marble
