LPG dispenser

FOB Price

Negotiable / Unit

1 Unit(Min.Order)

Supply Ability 5000 Unit / Units per Month
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin

Zhejiang, China

Product Description

Specifications

1.2mm thickness
Stainless Steel side panels & keypad
Baking finish,color as client like
Four nozzles
Breakaway valve

Product characteristics

1.install the breakaway valve and anti-explosive design , insure the safe production.
3.special appearance design, improve the figure of whole gas station.
4.re-display the fueling gas record after the power off.
5.print the bill optionally after fueling gas.
6.order special product for customers.

Components Installed(standard):
1.Electronic Unit
2.LPG Nozzle
3.LPG-1 Flowmeter
4.LPG Separator

Technical Specifications:
1.Accuracy: ±0.5%
2.Pressure Gauge Measuring Range:0~2.5MPa
3.Delivery Rate:13 to 65L/min
4.Display Resolution:0.01 liter
5.Flow Rate: 75 L/min
6.Automatic Temperature makes up: Range -40 to 45
7.Safety Return Valve: 1.6MPa
8.Pressure Gauge Measuring Range: 0~2.5MPa
9.Anti-Explosive ID: Exdm[ib]ib AT3
10.Register Range: 0.00 to 9800.00L or Yuan
11.Anti-Explosive Certificate Number: CE011154 CE011155 CE011156 CE011157
12.Totalizer Range:0.00 to 99999999999.99L or Yuan
13.Range of Price: 0.01 to 99.99Yuan/L
14.License of Manufacturing Metric Instrument:ZheZi00000625
15.Preset Min Value: 0.00 to 0.99L
16.Power Supply: AC380V±20% or AC220V±20%
