Specifications
Single case,angle-typeSuperior accuracy,wide range for all kinds of fuel
low friction ball bearings, fixed cam-type timing
The PD rotary vane meter are single case, angle-type,rotary vane, positive displacement meter.
Superior accuracy and a wide range of products from gasoline to kerosene to fuel oils can be metered.
Compact, versatile design can be readily fit into nearly all installations.
Low pressure drop meter results in low meter slippage and thus superior meter accuracy.
Long service life, low friction ball bearings, fixed cam-type timing, and rugged construction give sustained accuracy and long time operation.
Application includes: blending, batching,dispensing,inventory control, and custody transfer of oils, solvents, chemicals,paints, fats and fertilizers.
Technical Specification:
Model | FMC-50 | FMC-80 | FMC-100 |
Size | 50mm/2 | 80mm/3 | 100mm/4 |
Flow Rate Range(L/min) | 38-380 | 75-750 | 150-1500 |
Max. Working Pressure | 150PSI | ||
Accuracy | ±0.2% | ||
Repeatability | 0.07% | ||
