Home > Products > New Products > Ultrasonic Flaw Detector
Ultrasonic Flaw Detector
US$ 4,600 - 7,500
/ Set
1 Set(Min. Order)
- SHANGHAI
- T/T D/P D/A Money Gram Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | KBD | |
| Model Number | CTS-1008 | Power | Electronic | |
| Usage | Deformation Testing Machine |
Product Description
Specifications
WE CAN SUPPLY Ultrasonic Flaw Detector
| Up to 640MHz sampling frequency, measurement resolution of 0.1mm with minimum range of 2mm |
| Operating Frequency: 0.5 – 20MHz, surplus sensitivity up to 64dB |
| Bright, high resolution (640×480) color TFT display realizing the best measurement result in similar products |
| High performance square wave pulser with tuning option allows the operator to tune the pulse width of the square wave pulser to optimize transducer performance. This maximizes signal-to-noise and penetration in difficult materials such as highly-attenuated materials or thin work-pieces |
| Small dimension, lightweight, portable, fully-sealed, highly-reliable design especially suitable for working outdoors |
| LAN port allows remote data transfer and management. It provides management to instrument parameters when the instrument is used as independent square wave pulser |
| Two-dimensional incremental encoder interface realizes accurate position-detecting imaging (B-scan, C-scan, D-scan) |
| Synchronous analogue RF waveform output with impedance 50 Ohm make it a good signal source of data collection and transducer test |
| High-speed USB interface allows data storage on USB drive and PC communication. To interface with a mouse to secure accurate analysis on report with A-scan |
| Internal charger, auto switch between “charge” and “work”. Power supplied by battery or AC mains. The operating time of onboard Li battery is more than 6 hours |
| Multi-software functions to meet all inspection needs, unique keypad organization and rotary knob operation, user-friendly design for menu, English/Chinese language menu options, English/Chinese input and edit functions make the inspection much easier |
| Automatically test the transducer frequency, tune the pulse width of square wave pulse to optimize transducer performance |
| Thickness alarm function, continuous storage function of waveform and various measurement modes of waveforms |
| Automatically calibrate instrument specifications and search the peak value |
