Home > Transportation > Forklifts & Parts > Forklift > 3Tons Capacity Duplex Mast Diesel Powered Forklift With ISUZU C240 Engine

3Tons Capacity Duplex Mast Diesel Powered Forklift With ISUZU C240 Engine

Name: 3Tons Capacity Duplex Mast Diesel Powered Forklift With ISUZU C240 Engine
Brand: HUAHE
SKU: 143332794
Availability: InStock

3Tons Capacity Duplex Mast Diesel Powered Forklift With ISUZU C240 Engine thumbnail-1

3Tons Capacity Duplex Mast Diesel Powered Forklift With ISUZU C240 Engine photo-1

US$ 1 - 7,500 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Zhejiang, China

Brand Name:

HUAHE

Contact Supplier Request Quote Chat Now

Huahe Heavy Industries Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Zhejiang, China

Brand Name HUAHE

Model Number HH30Z-W1-D

Type Powered Pallet Truck

Power Souce Diesel Engine

Rated Loading Capacity 3T

Max. Lifting Height 2120mm

Min. Lifting Height 2095mm

Fork Length 1070mm

Fork Width 125mm

Overall Dimensions 2680X1225X2120mm

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

•When the fork lower to almost touch ground, •The seat can be adjusted back and front.

the cargo fork will decelerate to reduce impact The loading capacity of the seat can be

and noise. automaticlly according to body weight.

This series forklift trucks are widely used in factories, warehouses, wharves, ports and so on for loading, unloading and transporting of the packaged goods, besides, can be used for the handling of the bulk goods and unpackaged goods after equipping other attachments of forklift trucks.

Generals	Model		Unit	HH30	HH30Z
	Power type			Diesel
	Rated capacity		Kg	3000
	Load center		mm	500
Dimensions	Lift height		mm	3000
	Free lift height		mm	130
	Fork size (L×W×T)		mm	1070×125×45
	Mast inclination F/R		Deg	6°/12°
	Front overhang		mm	490
	Overall Dimensions	Length to face of fork	mm	2680
		Overall width	mm	1225
		Mast lowered height	mm	2095
		Overhead guard height	mm	2120
	Turning radius		mm	2460
	Min. right angle aisle width		mm	2105
Performance	Travel speed	Unload I/II	Km/h	9/20
		Full load I/II	Km/h	8.8/18.5
	Lift speed		mm/s	480
	Max. grade ability		%	20
	Max. drawbar pull		Kn	13
	Self weight		Kg	4400
Wheels & Tires	Tires	Front		28×9-15-12PR
		Rear		6.50-10-10PR
	Tread	Front Q	mm	1000
		Rear S	mm	970
	Wheelbase		mm	1700
	Min. ground clearance (unload/full load)	Mast	mm	152/132
		Frame	mm	158/138
Drive units & Control	Battery		V/Ah	12/90
	Engine	Model		ISUZU C240
		Rated output	Kw/rpm	34.5/2500
		Rated torque	N.m/rpm	139/1800
		Displacement	cc	2369
	Transmission	Type		Hydraulic
		Shift Fwd/Rwd		1/1 Power shift
	Operating pressure		Mpa	17.5
