3T 6M Chinese Engine Diesel Powered Forklift With Automatic Transmission

3T 6M Chinese Engine Diesel Powered Forklift With Automatic Transmission thumbnail-1
3T 6M Chinese Engine Diesel Powered Forklift With Automatic Transmission photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
HUAHE(Chinese Engine)
Contact Supplier Request Quote Chat Now
Huahe Heavy Industries Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name HUAHE(Chinese Engine)
Model Number HH30Z
Type Powered Pallet Truck
Power Souce Diesel Engine
Rated Loading Capacity 3Ton
Max. Lifting Height 6000mm
Min. Lifting Height 132mm
Fork Length 1070
Fork Width 125
Overall Dimensions 2.68m*1.225m*2.12m
Certification CE, ISO9001
After-sales Service Provided Engineers available to service machinery overseas





Generals

Model

Unit

HH30

HH30Z

Power type



Diesel

Rated capacity

Kg

3000

Load center

mm

500













Dimensions

Lift height

mm

3000

Free lift height

mm

130

Fork size (L×W×T)

mm

1070×125×45

Mast inclination F/R

Deg

6°/12°

Front overhang

mm

490





Overall Dimensions

Length to face of fork

mm

2680

Overall width

mm

1225

Mast lowered height

mm

2095

Overhead guard height

mm

2120

Turning radius

mm

2460

Min. right angle aisle width

mm

2105







Performance



Travel speed

Unload I/II

Km/h

9/20

Full load I/II

Km/h

8.8/18.5

Lift speed

mm/s

480

Max. grade ability

%

20

Max. drawbar pull

Kn

13

Self weight

Kg

4400









Wheels & Tires



Tires

Front



28×9-15-12PR

Rear



6.50-10-10PR



Tread

Front Q

mm

1000

Rear S

mm

970

Wheelbase

mm

1700

Min. ground clearance

(unload/full load)

Mast

mm

152/132

Frame

mm

158/138











Drive units & Control

Battery

V/Ah

12/90





Engine

Model



          C240     490BPG

Rated output

Kw/rpm

      34.5/2500   37/2650

Rated torque

N.m/rpm

     139/1800   145/1800

Displacement

cc

           3059       2400

Transmission

Type



Hydraulic

Shift Fwd/Rwd



1/1 Power shift

Operating pressure

Mpa

17.5
