3T Diesel Forklift

3T Diesel Forklift thumbnail-1
3T Diesel Forklift photo-1
US$ 1 - 7,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
HUAHE
Contact Supplier Request Quote Chat Now
Huahe Heavy Industries Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name HUAHE
Model Number HH30Z
Type Powered Pallet Truck
Power Souce Diesel Engine
Rated Loading Capacity 3000KGS
Max. Lifting Height 6000mm
Min. Lifting Height 3000mm
Fork Length 1070mm
Fork Width 125mm
Overall Dimensions 2680*1225*2120mm

3T Diesel Forklift

item no:HH30Z



3T Diesel Forklift
great Reliability of forklift
Forklift with Dual air filter
Forklift have reasonable price
CE,ISO9001 3T Diesel Forklift

Generals

Model

Unit

HH20

HH20Z

Power type



Diesel

Rated capacity

Kg

2000

Load center

mm

500

Dimensions

Lift height

mm

3000

Free lift height

mm

130

Fork size (L×W×T)

mm

1070×122×40

Mast inclination F/R

Deg

6°/12°

Front overhang

mm

482

Overall Dimensions

Length to face of fork

mm

2480

Overall width

mm

1150

Mast lowered height

mm

2095

Overhead guard height

mm

2120

Turning radius

mm

2320

Min. right angle aisle width

mm

1910

Performance

Travel speed

Unload I/II

Km/h

9/20

Full load I/II

Km/h

8.8/18.5

Lift speed

mm/s

480

Max. grade ability

%

20

Max. drawbar pull

Kn

14

Self weight

Kg

3720

Wheels & Tires

Tires

Front



7.00-12-12PR

Rear



6.00-9-10PR

Tread

Front Q

mm

970

Rear S

mm

970

Wheelbase

mm

1650

Min. ground clearance

(unload/full load)

Mast

mm

152/132

Frame

mm

158/138

Drive units & Control

Battery

V/Ah

12/90

Engine

Model



    C240       490BPG

Rated output

Kw/rpm

34.5/2500   37/2650

Rated torque

N.m/rpm

139/1800   145/1800

Displacement

cc

   3059          2400

Transmission

Type



Hydraulic

Shift Fwd/Rwd



1/1 Power shift

Operating pressure

Mpa

17.5
Product Description

Model: HH30Z
Power type: Diesel
Rated capacity: 3000
Load center: 500mm
Lift height: 3000mm
Free lift height: 142mm
Fork size(N*U*L): 1070*125*45mm
Mast tilt angle(K/T): 6/12deg
Front O-verhang: 497mm
Overall dimensions
Length to face of fork: 2730mm
Overall width: 1225mm
Mast lowered height: 2095mm
Overhead guard height: 2120mm
Turning radius: 2460mm
Min. Right angle aisle width: 2105mm
No load/full load
Travel speed(Forward): 18/19.5km/h
Travel speed(Backward): 18/19.5km/h
Lift speed: 400mm/sec
Max. Gradeability: 20%
Max. Drawbar pull: 13.5KN
Self weight: 4900kg
Tires(Front): 28x9-15-12PR
Tires(Rear): 6.50-10-10PR
Tread(Front Q): 1000mm
Tread(Rear S): 970mm
Wheelbase: 1700mm
Min. Ground clearance(no load/full load)
Mast: 135/110mm
Frame: 166/160mm
Battery: 12/105V/AH
Engine
Model: 490BPG
Rated output: 37/2650kw/rpm
Rated torque: 145/1800
Displacement: 2400CC
Transmissions(Type): Hydraulic
Transmissions(Shift Fwd/Rwd): 1/1 Power shift
Operating pressure: 17.5Mpa



about us:

We are a specialized manufacturer and exporter of gasoline generators, Forklift,gasoline engines, gas power water pumps and WHD series electric scooters. The products have stable quality and advanced technology and sell well in Japan, America, Europe, Southeast Asia etc.
