Stain Controled Electric Direct Shear Test for Soil
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Geotest Equipments
Model Number:
Direct Shear Apparatus
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai Negotiable
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CTA-P Single-lever Protable Consolidation Test ApparatusNegotiableMOQ: 1 Set -
DSA-P Portable Direct Shear ApparatusNegotiableMOQ: 1 Set
-
CTA-3 Triple Soil Consolidation Device OedometerNegotiableMOQ: 1 Set
-
Horizontal Field Direct Shear ApparatusNegotiableMOQ: 1 Set
-
SRA-1 Sample Reduction ApparatusNegotiableMOQ: 50 Pieces
Place of Origin
Zhejiang, China
Brand Name
Geotest Equipments
Model Number
Direct Shear Apparatus
Power
Electronic
Usage
Other, Direct Shear Apparatus
Specifications
Stain Controled Electric Direct Shear ApparatusEasy Operated Electric Direct
Stain Controled Electric direct shear test for soil
This Stain Controled Electric Direct Shear Apparatus is used to test the shearing resistance of soil specimen.The Stain Controled Electric Direct Shear Apparatus usually adopts four specimens under the different vertical pressure to add shearing force to carry on shear test to obtain the shearing force when the specimen is destroyed.Determine the shearing resistance coefficient, internal frictional angle and cohesion of the soil according to Coulomb's law.To choose this " Stain Controled Electric Direct Shear Apparatus " will not make you disppointed.
| Product Name | Stain Controled Electric Direct Shear Apparatus |
| Sample area | 30cm² |
| Sample thickness | 2cm |
| Max.vertical loading | 400Kpa |
| Loading Grade | 50,100,200,300,400Kpa |
| Lever ratio | 1:12 |
| Max.horizontal loading | 1.2Kpa |
| Relative weight of weights | 1.275,2055,5.1,7.65,10.2Kpa,hanging pan as per garde 1. |
| Rotation speed of handwheel | 4r.p.m,12r.p.m |
| Relative shear speed | 0.8mm/min,2.4mm/min |
| Axial diaplacement | 0.2mm as per rotation of the handwheel |
| Working voltage | 220V,50Hz |
| Certificate | ISO9001:2008 and any other certificates you need can be provided |
| Delivery Time | For sample order with 3 working days for general order with 5-15working days |
| Standards | BS1377/ASTM D3080 |
