TTA-6 BS Standard Triaxial Testing Apparatus

Name: TTA-6 BS Standard Triaxial Testing Apparatus
Brand: GEOTEST EQUIPMENT
SKU: 143207668
Availability: InStock

Shaoxing GeoTest Equipment Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

GEOTEST EQUIPMENT

Model Number:

TTA-6

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo Shanghai Negotiable

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name GEOTEST EQUIPMENT

Model Number TTA-6

Power Electronic

Usage Other, triaxial testing machine

TTA-6 BS standard triaxial testing apparatus

Product Description

To determine the drained and undrained shear strength parameters and effective shear strength paraneters of soil specimen.

"UU" unconsoildated underained test

"CU" consoildated undrained test

"CD" consoildated drained test

Specimens	Φ38x76mm, Φ50x100mm, Φ70x140mm, Φ100x200mm
Load capacity	60KN
Infinitesimal testing speed from 0.0024 to 4.5mm/min (16-speed mechanical transmission)
Working table travel	0-100mm
Cell pressure	0-2Mpa (digital, LCD display)
Drainage	0-1Mpa (digital, LCD display)
Pore pressure	0-2Mpa
Volume change	0-100ml/0.2ml (resolution)
Power	220V, 50Hz
Weight	240kg (includes: load frame, control device, pressure chamber, specimen tools and accessories)
