DSA-3 Three-speed Electric Soil Strain Direct Shear Apparatus
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GEOTEST EQUIPMENTS
Model Number:
DSA-3
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai Negotiable
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
GEOTEST EQUIPMENTS
Model Number
DSA-3
Power
Electronic
Usage
Other, Direct Shear Apparatus
DSA-3 Three-speed Electric Soil Strain Direct Shear Apparatus
Standard: BS 1377, ASTM D3080
Features:
a. Shear apparatus is a kind of strain controlled direct shear apparatus used to test the shearing resistance of soil specimen.
b. It usually adopts four specimens under the different vertical pressure to add shearing force to carry on shear test to obtain the shearing force when the specimen is destroyed.
c. Determine the shearing resistance coefficient, internal frictional angle and cohesion of the soil according to Coulomb's law.
Our products are 100% supplied from the factory
If you are interested in our products, you can contact us directly or welcome to visit our site:
SKYPE ID: sun.nancy3
| Sample area | 30cm² | |||||
| Sample thickness | 2cm |
|||||
| Max.vertical loading | 400Kpa | |||||
| Loading grade | 50, 100, 200, 300, 400Kpa | |||||
| Lever ratio | 1:12 | |||||
| Max.horizontal loading | 1.2KN | |||||
| Relative weight of weights | 1.275, 2.55, 5.1, 7.65, 10.2Kpa, hanging pan as per grade 1 | |||||
| Rotation speed of handwheel | 0.1r.p.m., 4r.p.m., 12r.p.m. | |||||
| Axial displacement is 0.2mm as per rotation of the handwheel | ||||||
| Relative shear speed | 0.02mm/min, 0.8mm/min, 2.4mm/min | |||||
| Working voltage | 220V, 50Hz | |||||
