CTA-KO KO Consolidation Test Apparatus
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GEOTEST EQUIPMENTS
Model Number:
CTA-KO
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai Negotiable
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SLT-V Shrinkage Limit Test / Volumetric Shrinkage Limit TesterNegotiableMOQ: 20 Sets -
DSA-1R Soil Ring Shear MachineNegotiableMOQ: 1 Set
-
DSA-8 Soil Test Machine Creep Direct Shear MachineNegotiableMOQ: 1 Set
-
PTA-3 Coarse Soil Permeability Testing MachineNegotiableMOQ: 1 Set
-
SS2 Oak Field Soil Sampling KitNegotiableMOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
GEOTEST EQUIPMENTS
Model Number
CTA-KO
Usage
Other, Consolidation Test Apparatus
CTA-KO KO Consolidation Test Apparatus
Standard: ASTM D2435, D4546, AASHTO T216
Features:
a. KO Consolidation Apparatus is used to determine static lateral pressure coefficient of soil.
| Sample diameter | 61.8mm | |||||
| Sample height | 40mm | |||||
| Axial load | 6KN | |||||
| Load pressure | 0-1000Kpa | |||||
| Axial diaplacement | 0-10mm | |||||
| Working temperature | 20°c±5°c | |||||
| Relative humidity | <85% | |||||
| Relative error of load ring | <±1‰ | |||||
| Relative error of height | <±2‰ | |||||
| Relative error of axial displacement | 0.03mm/min. division 0.01mm | |||||
| Pressure chamber is without leakage under rating load and the variation is smaller than 0.20ml | ||||||
