Home > Instruments & Meters > Test Instrument > Test Machine > DSA-8 Soil Test Machine Creep Direct Shear Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Geotest Equipments
Model Number:
DSA-8
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai Negotiable
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
Geotest Equipments
Model Number
DSA-8
Power
Electronic
Usage
Other, Direct Shear Test Apparatus
Soil Test Machine Creep Direct Shear Apparatus
Product Description
Features:
a. The Soil Test Machine Creep Direct Shear Apparatus is used to load vertical pressure and shearing force on cutting surface of soil sample, to measure the shearing deformation to determine the creep resistance of soil under the condition of loading pressure.
| Sample size | Φ61.8x20mm, area as 30cm² | |||||
| Max. shearing force | 1.8KN | |||||
| Max. vertical force | 0.8Mpa | |||||
| Lever ratio | 12:1 | |||||
| Vertical deformation range | 0-10mm, accuracy: ±1% | |||||
| Horizontal deformation range | 0-10mm, accuracy: ±1% | |||||
| Power supply | 220V, 50Hz | |||||
