Home > Instruments & Meters > Test Instrument > Test Machine > TTA30-2 Soil Triaxial Shear Test Apparatus
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GEOTEST EQUIPMENT, GEOTEST EQUIPMENTS
Model Number:
TTA30-2
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai Negotiable
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TTA10-2 Triaxial Soil Shearing Strength TestsNegotiableMOQ: 1 Set -
TTA10-1 Bench Triaxial Testing ApparatusNegotiableMOQ: 1 Set
-
LPLD-2 Clay Soil Moisture Cotent Limit Testing Apparatus Liquid Plastic Limit DeviceNegotiableMOQ: 1 Set
-
LPLD-3 Digital Liquid Plastic Limit DeviceNegotiableMOQ: 1 Set
-
DSA-8 Soil Test Machine Creep Direct Shear ApparatusNegotiableMOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
GEOTEST EQUIPMENT, GEOTEST EQUIPMENTS
Model Number
TTA30-2
Power
Electronic
Usage
Other, Soil triaxial shear test apparatus, Soil triaxial shear test apparatus
Soil triaxial shear test apparatus
Features:
a. Used to determine the shear resistance of soil to measure the stability of soil structure.
b. Total stresses are normally measured in a triaxial cell where the sample is subject to an all round confining pressure.
c. A load is applied through a piston onto a pressure pad, with the sample being confined within a rubber membrane so that no drainage in or out of the specimen is allowed.
d. Infinitesimal testing speed from 0.001 to 3mm/min (stepless adjustable)
Soil triaxial shear test apparatus
| Model | TTA30-2 |
| Sample size | Φ39.1×80mm |
| Load capacity | 30KN |
| Infinitesimal testing speed from 0.001 to 3mm/min(stepless adjustable) | |
| Working table stroke | 0-80mm |
| Cell pressure | 0-2000Kpa |
| Drainage | 0-1000Kpa |
| Pore pressure | 0-2000Kpa |
| Volume change | 0-50 cm³ |
| Axial displacement | 0-20mm(digital gauge) |
Soil triaxial shear test apparatus
The biggest manufactor is in china, the top quality is in china, the best service is also in china!
Pls believe GEOTEST, Believe China Power!
We sincerely lookinf forward to cooperate with you!
