PSV-2 Skid Resistance & Friction Tester (Skid Tester)
Standard: EN 1097-8, EN 13036-4, BS 812, ASTM E303
1. Characteristics
a. This apparatus consists of a spring-loaded rubber slider mounted on a pendulum arm.
b. The arm can be adjusted vertically from a rigid support column when in operation.
c. The base has three adjustable feet so that the swing of the pendulum during test moves through a truly circular path while operating directly on a road surface.
d. All bearings and working parts are enclosed where possible to protect them against wear and contamination.
Our products are 100% supplied from the factory
If you are interested in our products, you can contact us directly or welcome to visit our site:
SKYPE ID: sun.nancy3
| Pendulum weight | 1500g | |||||
| Moment of pendulum's barycenter | 410mm | |||||
| Face-on static pressure | 22.2N(2263g) | |||||
| Distance between edge and center of pendulum | 508mm | |||||
| Pendulum's sliding distance on pavement | 126mm | |||||
| Overall dimensions | 700mmx360mmx700mm | |||||
| Weight approx | 30kg | |||||
