STD-500 Solid Test Drum Coal Drum Testing Machine
1. Application
The Solid Test Drum is used for determination of coke resistance to fragmentation.
2. Structure
The machine is made of the drum,lifting flights,access door,motor,controller, counter and so on.
3. Main Technical Parameter
3.1 Cylindrical steel drum: diameter of 1000±5 mm, length of 500±5 mm.
3.2 Thickness: 10 mm
3.3 The size of opening: 400x500 mm (L x W x H)
3.4 Counter: can be adjustable from 1 to 999 (built-in inside controller)
3.5 Rotation speed: 25±1 RPM
3.6 Outside dimensions: about 1350x1020x1520mm(L x W x H)
3.7 Power: 220V, 50Hz, 1.5KW, three-phase
