Home > Manufacturing & Processing Machinery > Machine Tools > Planer > Slotting Machine/slot Machine/slot/slot Cabinet

Slotting Machine/slot Machine/slot/slot Cabinet

Name: Slotting Machine/slot Machine/slot/slot Cabinet
Brand: SMAC
SKU: 143012156
Availability: InStock

Slotting Machine/slot Machine/slot/slot Cabinet thumbnail-1

Slotting Machine/slot Machine/slot/slot Cabinet photo-1

US$ 500 - 50,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Jiangsu, China

Brand Name:

SMAC

Contact Supplier Request Quote Chat Now

SJR Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Jiangsu, China

Brand Name SMAC

Model Number B5050A

Specifications

Slotting Machine/slot machine/slot/slot cabinet
This vertical planing machine is suitable for vertical planing active surfaces

Slotting Machine/slot machine/slot/slot cabinet

Feature:
This vertical planing machine is suitable for vertical planing active surfaces of parts and notch etc.
The machine runs smoothly owing to it adopts double crank mechanism. The machine
operates easily because motion of the working table is driven by electric motor.
It has a pump for lubrication and cooling cutting tool and workpiece.

MODEL	B5050A
Max. slotting length	500mm
Table diameter	1000mm
Cross traverse of work table	660mm
Longitudinal traverse of work table	1000mm
Max. weight of workplece	2000kg
Distance between tool holding Surface and column front	1000mm
Range of ram adjustment	430mm
Distance between worktable and the lower side of slide	740mm
Inclination of ram head (Left or right directions)	+100deg
Number of ram strokes (per min.)	9, 12.5, 18, 25, 36, 50.
Longitudinal and cross feeds of worktable (mm. per ram stroke)	0.1, 0.2, 0.3, 0.4, 0.6, 1.2mm
Rotary feeds of worktable (min per ram stroke)	3, 6, 9, 12, 18, 36 dr/per
Max. cutting force	1600N
Rapid travers motor	1.5kw 1440r.p.m
Main motor	7.5kw 1440r.p.m
Coolant pump motor	0.125kw 2800r.p.m
Net weight of machine (approx.)	10.3t
Overall dimensions (L x W x H)	3480 x 2085 x 3307mm
