radial drilling machine
Specifications
1. Hydraulic clamping.
2. Hydraulic transmission.
3. Hydraulic preselection.
4. Electrical machinery double protection
Product Descriptio
Model URD25 Portable Type Universal Radial Drilling Machine:
The machine can be used in any direction to act on the workpiece for dirlling. reaming, spotting and thread tapping.
Suitable for small-lot protting and thread tapping.
Suitable for small-lot production and for machining large-sized and heavy-duty workpiece in assembling and repair shop.
The arm can lifting rapidly and operate easilly.
radial drilling machine
| Model | URD25 | |
| Max. drilling dia. | mm | 25 |
| Distance of spindle centre line to column surface | mm | 330-820 |
| Distance of spindle nose to table surface | mm | 820-860 |
| Taper hole of spindle | Morse No.3 | |
| Spindle speed | r/min | 175, 425, 687, 960 |
| Travel of spindle | mm | 130 |
| Swivel angle of arm | deg | 360 |
| Size of table (L x W) | mm | 600 x 520 |
| Main motor power | kw | 1.5 |
| Net weight | kg | 820 |
| Gross weight | kg | 1300 |
| Overall dimensions (L x W x H) | mm | 1768 x 725 x 1984 |
| Packing box dimension (L x W x H) | mm | 2040 x 976 x 2428 |
product show
radial drilling machine
Our service:
1,Your inquiry will be replied in 24 hours.
2.Our manufacture/company has been a Gold supplier continuously in this Alibaba website for 6
years.And there is more industry technology experience for 20 years with our manufactures
3.To offer free spare parts and service within one year of warranty
4.Technology Support Provide operation video for training
5.Professional after-sales service team
6.Give reasonable offers with the best quality
Our advantage:
1,More then 20 years experience for indusry product
2,All modles with CE,TUV,SGS,ISO9001/9002 or other authority approved
3,Professional service and technology
4,Excellent reputation all over the world
5,Final exported producuts would pass strict test by international authority BIVAC
6, There is more exporting experience for 20years with our owned manufacture/company
Welcome to Almaco Machine Tool Co., Ltd
our company as the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation,specializes in import & export of brand-new industrial machinery & tools.Our mechanical products with ISO9001 or CE certificate cover more than 80 kinds including lathe ,milling machine,grinding machine,power press,guillotine shearer,hydraulic press brake,CNC Machine and so on,which have been exported to 40 or more countries & areas.
We are looking forward to bulding sincere and long-term business relationship with you
