Hydraulic Splitter (Pneumatic Engine)
US$ 1 - 1,500
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New, New
Application:
splitter rock, Ore, quarry, demolition, construction
Motor Type:
Other
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hydraulic Stone Splitter DS80A-DS90EUS$ 1 - 2MOQ: 1 Set -
Hydraulic Rock Splitter With Power Pack for Natural StoneNegotiableMOQ: 1 Set
-
Hydraulic Stone Splitter DS80A-DS90EUS$ 1 - 2MOQ: 1 Set
-
Rock Splitter MachineUS$ 1 - 1,500MOQ: 1 Unit
-
Pneumatic Engine Hydraulic Stone Split Tool for MarbleUS$ 1 - 1,000MOQ: 1 Set
Application
splitter rock, Ore, quarry, demolition, construction
Motor Type
Other
Power(W)
4000-7000
Place of Origin
Fujian, China
Brand Name
DSL
Model Number
DS90E
Dimension(L*W*H)
1.3*1*1M including power station size
Certification
CE, CE
Warranty
2 month
Hydraulic splitter (Pneumatic engine)
1.Instruction
DS90E Hydraulic splitter means controlled demolition. As the direction of breaks can be determined, concrete can be cut in sections as large as your equipment can handle. Hydraulic splitting eliminates both shocks and vibrations associated with large impact tools
2.Specification
| Model | Hole diameter (MM) |
Piston inside diameter (MM) |
Minimum drilling depth (MM) |
Wedge length (MM) |
Crack width (MM) |
Splitting time (S) |
Theory division force (T) |
Actual division force (T) |
Single weight (KG) |
|---|---|---|---|---|---|---|---|---|---|
| DS80A | Φ38~42 | 80 | ≥450 | 150 | 10~40 | 5~12 | 500 | 280 | 20 |
| DS80B | Φ40~42 | 80 | ≥500 | 200 | 10~40 | 5~12 | 600 | 300 | 21 |
| DS80C | Φ40~42 | 80 | ≥600 | 300 | 10~40 | 5~12 | 680 | 420 | 25 |
| DS80D | Φ45~48 | 80 | ≥800 | 450 | 10~40 | 5~12 | 720 | 450 | 27 |
| DS90A | Φ38~42 | 90 | ≥450 | 150 | 10~40 | 5~12 | 680 | 420 | 26 |
| DS90B | Φ40~42 | 90 | ≥500 | 200 | 10~40 | 5~12 | 720 | 450 | 26.5 |
| DS90D | Φ40~42 | 90 | ≥600 | 300 | 10~40 | 5~12 | 780 | 480 | 27 |
| DS90E | Φ45~48 | 90 | ≥700 | 380 | 10~40 | 5~12 | 820 | 500 | 28 |
Pictures of Hydraulic splitter
Working photos.
Hydraulic splitter cylinder and wedges
Gasoline type hydraulic power unit
Diesel type hydraulic power unit
Eletric type hydraulic power unit
Hand type hydraulic portable power unit
Pneumatic type hydraulic power station
Package for hydraulic splitter
