Specifications
long fiber nonwoven geotextileexcellent permeabitlity
good flexiblity
acquired and durability
easy for constr
long fiber nonwoven geotextile
long fiber nonwoven geotextile introduction
We supply a range of both polypropylene and polyester geotextiles used for separation, filtration and reinforcement applications. These include: needle punched staple fibre geotextiles; continuous filament spunbonded geotextiles; stitch reinforced non woven fabrics and thermal embossed fabrics suitable for reusable carry bags with an exceptional degree of uniformity.
The company's modern equipment, ISO9001 accreditation, continuous development and investment programme delivers geotextiles manufactured to the highest international standards. Each batch laboratory tested and certified.
Our highly uniform non-woven fabrics are used in Australian coating factories to manufacture termite barriers, waterproof liners and high performance petrolatum wax tapes.
long fiber nonwoven geotextile features
High porosity - allows air & water to permeate
Helps reduce weed growth
Reduces sinkage
Stops mixing of substrates with top dressings
Reduces depth of sub-base required
Variety of sizes available to suit your project and to minimise waste
Calendered both sides for extra strength
long fiber nonwoven geotextile Specification:
Material |
PET,PP |
Technics/process |
Needle punched / thermally bonded |
Specification |
100g/m2-1200g/m2 |
Width |
1m-6m(as you demand) |
Length |
100m(as you demand) |
Colour |
White, black, grey, green, brown, etc. |
Packing |
PE film and woven cloth |
Load |
According to your specification |
Payment terms |
T/T or L/C |
Delivery time |
Within 2 weeks |
Application |
Geotextiles with various indicators of quality, with good stress -- strain and toughness, seepage performance and uniformity, and width, etc., And is applicable to roads, water, rail, mining dams, rivers, airports and other civil engineering, anyone in the works played reinforcement, segregation, filtration, filtration, drainage, and then extend the project life, reduced cost and easy construction, and it is easy to ensure the quality of the project. |
long fiber nonwoven geotextile Application:
Permeable Non-woven Geotextile Membrane are available for subgrade separation, reinforcement and applications such as reinforcing soils where extremely high tensile strength with low elongation is required. High strength woven polyester geotextiles are used in a wide range of projects including:
1, Water conservancy project dams and slope of filtration , channel isolation, impervious ;
2, Highways , railways, airport runways based isolation, filtration , drainage, slopes, retaining walls and pavement reinforcement, drainage ;
3, Port engineering soft ground , beach causeway , harbor piers and breakwaters reinforcement, drainage ;
4, Polyester filament geotextile has been widely used in the field of infrastructure construction , and gradually be applied to a wider range of fields.
long fiber nonwoven geotextile Index
Item |
Value |
||||||||||||||
Nominal Breaking Strength KN/m≥ |
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
||||||
1 |
Breaking Strength (CD/CMD)KN/m≥ |
4.5 |
7.5 |
10.0 |
15.0 |
20.0 |
25.0 |
30.0 |
40.0 |
50.0 |
|||||
2 |
Elongation at Break % |
40-80 |
|||||||||||||
3 |
CBR Mullen Burst Strength KN≥ |
0.8 |
1.6 |
1.9 |
2.9 |
3.9 |
5.3 |
6.4 |
7.9 |
8.5 |
|||||
4 |
Tear Strength (CD/CMD) KN≥ |
0.14 |
0.21 |
0.28 |
0.42 |
0.56 |
0.70 |
0.82 |
1.10 |
1.25 |
|||||
5 |
Sieve Size O90 mm |
0.05-0.20 |
|||||||||||||
6 |
Vertical Permeability Coefficient cm/s |
(1.0-9.9)×(10-1~10-3) |
|||||||||||||
7 |
Thickness mm≥ |
0.8 |
1.2 |
1.6 |
2.2 |
2.8 |
3.4 |
4.2 |
5.5 |
6.8 |
|||||
8 |
Unit Weight g/m2 |
100 |
150 |
200 |
300 |
400 |
500 |
600 |
700 |
800 |
|||||
9 |
Width Variation % |
-0.5 |
|||||||||||||
10 |
Weight Variation % |
-5 |
|||||||||||||
pls feel free to contact us:
