Specifications
240g PP geotextile sheetMaterial:PP/PET recycled or virgin
Width:1-6m
Weight:100-1200gsm
White/black
240g PP geotextile sheet
240g PP geotextile sheet Introduction:
1.Geotextile has good air and water permeability to let water flow through it so as to effectively control sandrock running-down.
2.Geotextile has good water transmissibility, it can form drainage channels inside soil mass to drain redundant liquid and air out of the soil mass.
3.Geotextile helps to enhance the soil mass' tensile strength and non-deformability and structural stability so as to improve soil mass quality.
240g PP geotextile sheet Feature:
- Geotextile has good air permeability and water permeability which can pass the water out and intercept the sand running-down
- Geotextile has high water diversion property, it can form drainage passageway, transpire the surplus liquid and gas
- High water permeability even under the pressure of soil and water
- Spread, transfer or decompose the concentrate stress effectively to avoid the soil be damaged by outside affection
- To prevent the freestone upper and lower level, soil and concrete mixed
- Polypropylene fiber or polyester fiber and other chemical fiber as raw material, acid-alkali-proof, non-corrording, non warm-eaten,antioxidant
- Light weight, convenient to use, easy construction, shorten working-period, increase economic efficiency
- Make use of geotextile to strengthen the tensile strength and anti-deformation property of soil, increase the stability of building structure, and also improve the soil quality
240g PP geotextile sheet Application:
1,geotextile has good air permeability and water permeability, allowing the water to flow through, so as to effectively intercept sandy soil erosion
2,Geotextile has excellent hydraulic conductivity, it can form a drain channel inside the soil ,to eliminate excess liquid and gas.
3,Using geotextiles to enhance the tensile strength of the soil and deformation resistance, enhanced stability of the building structure, to improve the quality of the soil.
4,The concentration diffusion, transfer or decomposition, preventing soil from the external force destruction.
5,To prevent the up-down layer sand, soil and concrete from mixing.
6,The mesh is not easily blocked: Because the amorphous formation of fibrous tissue in the reticular structure can be changed.
7,High water permeability: under water pressure can still maintain good water permeability.
8,Corrosion resistance, use polypropylene or polyester, chemical fiber as raw material, acid and alkali resistance, no corrosion.
9,Construction, light weight, convenient to use, simple construction.
240g PP geotextile sheet Index:
Item |
Specification |
||||||||
100 |
150 |
200 |
300 |
400 |
500 |
600 |
800 |
1000 |
|
|
Nominal Breaking strength,KN/M
|
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
|
Breaking strength,MD/CD,KN/M≥
|
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
|
Elongation at break,%
|
40-80 |
||||||||
|
CBR Mullen Burst Strength,KN≥
|
0.8 |
1.6 |
1.9 |
2.9 |
3.9 |
5.3 |
6.4 |
7.9 |
8.5 |
|
Tear strength,KN≥
|
0.14 |
0.21 |
0.28 |
0.42 |
0.56 |
0.70 |
0.82 |
1.10 |
1.25 |
|
Sieve size O90(O95),mm
|
0.05-0.20 |
||||||||
Vertical Permeability Coefficient, cm/s |
K×(10-1-10-3), K=1.0-9.9 |
||||||||
Thickness,mm≥ |
0.8 |
1.2 |
1.6 |
2.2 |
2.8 |
3.4 |
4.2 |
5.5 |
6.8 |
Width Variation,% |
-0.5 |
||||||||
Weight Variation,% |
-5 |
||||||||
Remarks |
We also can produce almost double Strength higher than the chart show |
||||||||
