Specifications
geotextile silt fence for protectingMaterial:PP/PET recycled or virgin
Width:1-6m
Weight:100-1200gsm
White/black
geotextile silt fence for protecting
geotextile silt fence for protecting Introduction:
1.Geotextile has good air and water permeability to let water flow through it so as to effectively control sandrock running-down.
2.Geotextile has good water transmissibility, it can form drainage channels inside soil mass to drain redundant liquid and air out of the soil mass.
3.Geotextile helps to enhance the soil mass' tensile strength and non-deformability and structural stability so as to improve soil mass quality.
geotextile silt fence for protecting Feature:
Geotextile has good air and water permeability to let water flow through it so as to effectively control sandrock running-down.
Geotextile has good water transmissibility, it can form drainage channels inside soil mass to drain redundant liquid and air out of the soil mass.
Geotextile helps to enhance the soil mass' tensile strength and non-deformability and structural stability so as to improve soil mass quality.
It can effectively make the concentrated stress diffuse, transfer or decompound, and prevent the soil mass against the destruction of outside force.
It can prevent the mixture of sandstone, soil mass and concrete of upper and lower layers.
Its mesh is hard to jam by virtue of the compliancy and motility of the reticulation formed by indefinite form fibrous tissue.
High water permeability-it can keep good water permeability even in the pressure of soil and water.
Corrosion resistant-it is made from polypropylene fiber or terylene or other chemical fiber, featuring resistance to acid and alkali and oxidation, non-corroding, no worm-eaten.
geotextile silt fence for protecting Application:
1,geotextile has good air permeability and water permeability, allowing the water to flow through, so as to effectively intercept sandy soil erosion
2,Geotextile has excellent hydraulic conductivity, it can form a drain channel inside the soil ,to eliminate excess liquid and gas.
3,Using geotextiles to enhance the tensile strength of the soil and deformation resistance, enhanced stability of the building structure, to improve the quality of the soil.
4,The concentration diffusion, transfer or decomposition, preventing soil from the external force destruction.
5,To prevent the up-down layer sand, soil and concrete from mixing.
6,The mesh is not easily blocked: Because the amorphous formation of fibrous tissue in the reticular structure can be changed.
7,High water permeability: under water pressure can still maintain good water permeability.
8,Corrosion resistance, use polypropylene or polyester, chemical fiber as raw material, acid and alkali resistance, no corrosion.
9,Construction, light weight, convenient to use, simple construction.
geotextile silt fence for protecting Index:
Item |
Specification |
||||||||
100 |
150 |
200 |
300 |
400 |
500 |
600 |
800 |
1000 |
|
|
Nominal Breaking strength,KN/M
|
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
|
Breaking strength,MD/CD,KN/M≥
|
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
|
Elongation at break,%
|
40-80 |
||||||||
|
CBR Mullen Burst Strength,KN≥
|
0.8 |
1.6 |
1.9 |
2.9 |
3.9 |
5.3 |
6.4 |
7.9 |
8.5 |
|
Tear strength,KN≥
|
0.14 |
0.21 |
0.28 |
0.42 |
0.56 |
0.70 |
0.82 |
1.10 |
1.25 |
|
Sieve size O90(O95),mm
|
0.05-0.20 |
||||||||
Vertical Permeability Coefficient, cm/s |
K×(10-1-10-3), K=1.0-9.9 |
||||||||
Thickness,mm≥ |
0.8 |
1.2 |
1.6 |
2.2 |
2.8 |
3.4 |
4.2 |
5.5 |
6.8 |
Width Variation,% |
-0.5 |
||||||||
Weight Variation,% |
-5 |
||||||||
Remarks |
We also can produce almost double Strength higher than the chart show |
||||||||
