Specifications
270g PET Geotextile for tunnelexcellent permeabitlity
good flexiblity
acquired and durability
easy for constr
270g PET Geotextile for tunnel
270g PET Geotextile for tunnel introduction
Geotextiles are permeable fabrics which offer a cost-effective engineered alternative for scarce and difficult to locate natural construction materials. Geotextiles are used in many applications such as drainage, filtration, separation and soil reinforcement, while often being used to improve the performance of civil engineering and construction projects including roads, railways, and landfills
tunnel geotextile fabric features
- High extensibility and extremely robust to resist installation and in-service conditions
- Wide widths for minimum overlap (6m wide - 5.9m for export) saving on overlap wastage
- Very high permeability at all strains with negligible uplift in wave conditions
- Very good sand tightness at all strains retaining subsoil without washout
tunnel geotextile fabric Specification:
Material |
PET,PP |
Technics/process |
Needle punched / thermally bonded |
Specification |
100g/m2-1200g/m2 |
Width |
1m-6m(as you demand) |
Length |
100m(as you demand) |
Colour |
White, black, grey, green, brown, etc. |
Packing |
PE film and woven cloth |
Load |
According to your specification |
Payment terms |
T/T or L/C |
Delivery time |
Within 2 weeks |
Application |
Geotextiles with various indicators of quality, with good stress -- strain and toughness, seepage performance and uniformity, and width, etc., And is applicable to roads, water, rail, mining dams, rivers, airports and other civil engineering, anyone in the works played reinforcement, segregation, filtration, filtration, drainage, and then extend the project life, reduced cost and easy construction, and it is easy to ensure the quality of the project. |
tunnel geotextile fabric Index
Item |
Unit |
indication
|
|||||||||||
|
Per unit area
|
g/m2
|
100
|
150 |
200 |
250 |
300 |
350 |
400 |
450 |
500 |
600 |
800 |
1000
|
Thickness |
mm≥ |
0.9
|
1.3 |
1.7 |
2.1 |
2.4 |
2.7 |
3.0 |
3.3 |
3.6 |
4.1 |
5.0 |
5.9 |
|
Tensile strength
|
KN/m≥ |
2.5 |
4.5 |
6.5 |
8.0 |
9.5 |
11.0 |
12.5 |
14.0 |
16.0 |
19.0 |
25.0 |
28.0 |
|
Elongation
|
%≥ |
25`100 |
|||||||||||
CBR bursting strength |
KN≥ |
0.3
|
0.6 |
0.9 |
1.2 |
1.5 |
1.8 |
2.1 |
2.4 |
2.7 |
3.2 |
4.0 |
4.5 |
Equivalent opening size (O90) |
mm |
0.07`0.2 |
|||||||||||
Vertical permeability coefficient |
cm/s |
KX(10-9`10-12) K=1.0`9.9 |
|||||||||||
Tear strength |
KN≥ |
0.08
|
0.12 |
0.16 |
0.20 |
0.24 |
0.28 |
0.33 |
0.38 |
0.42 |
0.46 |
0.60 |
0.70 |
pls feel free to contact us:
