under turf geotextile

Specifications

under turf geotextile
excellent permeabitlity
good flexiblity
acquired and durability
easy for constr

                                                   under turf geotextile

under turf geotextile introduction

We supply a range of both polypropylene and polyester geotextiles used for separation, filtration and reinforcement applications. These include: needle punched staple fibre geotextiles; continuous filament spunbonded geotextiles; stitch reinforced non woven fabrics and thermal embossed fabrics suitable for reusable carry bags with an exceptional degree of uniformity.

The company's modern equipment, ISO9001 accreditation, continuous development and investment programme delivers geotextiles manufactured to the highest international standards. Each batch laboratory tested and certified.

Our highly uniform non-woven fabrics are used in Australian coating factories to manufacture termite barriers, waterproof liners and high performance petrolatum wax tapes.



under turf geotextile  features



High porosity - allows air & water to permeate

Helps reduce weed growth

Reduces sinkage

Stops mixing of substrates with top dressings

Reduces depth of sub-base required

Variety of sizes available to suit your project and to minimise waste

Calendered both sides for extra strength



Geotextile safty mat Application:

Permeable Non-woven Geotextile Membrane are available for subgrade separation, reinforcement and applications such as reinforcing soils where extremely high tensile strength with low elongation is required. High strength woven polyester geotextiles are used in a wide range of projects including:

• Block paviour drives
• Domestic patios
• Under cellular grids
• Land drains
• Attenuation & harvesting tanks
• Under turf
• Stabilisation using a vibrating plate
• Under wet pour/safety mats
• Horse Menege between type 1 & top dressing
• Retaining walls

under turf geotextile Index



Item		Value
Nominal Breaking Strength  KN/m≥		4.5		7.5		10		15	20	25	30		40		50
1	Breaking Strength  (CD/CMD)KN/m≥	4.5		7.5		10.0		15.0	20.0	25.0	30.0		40.0		50.0
2	Elongation at Break  %	40-80
3	CBR Mullen Burst Strength KN≥	0.8		1.6		1.9		2.9	3.9	5.3	6.4		7.9		8.5
4	Tear Strength  (CD/CMD) KN≥	0.14		0.21		0.28		0.42	0.56	0.70	0.82		1.10		1.25
5	Sieve Size O90 mm	0.05-0.20
6	Vertical Permeability Coefficient     cm/s	(1.0-9.9)×(10-1~10-3)
7	Thickness   mm≥	0.8	1.2		1.6		2.2		2.8	3.4	4.2	5.5		6.8
8	Unit Weight g/m2	100	150		200		300		400	500	600	700		800
9	Width Variation  %	-0.5
10	Weight Variation %	-5
