Bridge Abutments Geotextile
- 10000 Square Meter / Square Meters per Month
- qingdao
- T/T D/P D/A Credit Card PayPal
- Mesh interwoven drainage board, plastic geotextile mat, seepage drainage 30mm thick
- 10mm thick 13kg flexible composite cement blanket with compressive strength of 40Mpa and flexural strength of 20Mpa
- Cement blanket 10mm thick, weighing 12.5kg, 2 meters wide, and 50 meters long
- Mesh interwoven drainage board, plastic geotextile mat, seepage drainage 30mm thick
- 3cm thick mesh interwoven drainage board plastic geotextile mat
- Polypropylene Geotextile 800g polyester long fiber geotextile white
Product Description
Specifications
Bridge Abutments GeotextileMaterial:virgin or recycled
Weight: 100G/M2-1200G/M2
Width: 1-6m
Longth:50m
Bridge Abutments Geotextile
Bridge Abutments Geotextile Introduction:
Geotextile are made from 100% staple polyester and polypropylene needle-punched filter fabric. They have excellent waterflow rates and drainage for the filtration of soil fines. Non-woven Geotextiles have a variety of uses, some of which include trench drains and wrapping perforated pipe to protect against erosion and being combined with geomembranes to provide protective cushioning. Other uses include tensile reinforcement, filtration, and separation for roads, roofs, railroads, ponds, dams, trenches, landfills, protection for shoreline and membrane liners, sub-grade stabilization, erosion control, and many other civil engineering and construction uses. This product is resistant to tears and punctures, soil chemicals, UV rays, mildew, and freeze thaw.
Bridge Abutments Geotextile Feature:
1.Good water permeability
2.Corrosion resistance
3.Microbial resistant
4.Good permeability
5.Good water conductivity
6.High tensile strength
7.Strong resistance to deformation
8.The mesh is not easily blocked
Bridge Abutments Geotextile Application:
Industry | geotextile fabric, water proofing fabric, filter material, roadbed cloth, bank protecting cloth, insulation materials, cement bag, landfill,controlling erosion , ground reinforcement,soil seperation, ground drainage,controlling weeds, structure drainage,etc |
Garment | Shoulder pads ,face mask ,shoes cover /insoles, chest piece fabric, chest piece fabric,bra fabric,sleeve article cage, cap/hat/bag lining, ,etc
|
|
leg non-slip pad,etc |
| |
Decotation | lining of luggage bags,handicraft , festival decoration, automobile interior,roof lining fabric ,etc |
Agriculture | Geotextile ,protection material ,grow bags , felt pots, filter bag,etc
|
Bridge Abutments Geotextile Specification:
NO. | Item Value | Specification | Note | ||||||||||
| 100 g | 150g | 200g | 250 g | 300 g | 350 g | 400 g | 450 g | 500 g | 600 g | 800 g | ||
1 | Weight Variation% | -8 | -8 | -8 | -8 | -7 | -7 | -7 | -7 | -6 | -6 | -6 |
|
2 | Thickness mm≥ | 0.9 | 1.3 | 1.7 | 2.1 | 2.4 | 2.7 | 3.0 | 3.3 | 3.6 | 4.1 | 5.0 | |
3 | Width Variation % | -0.5 | |||||||||||
4 | Breaking Strength KN/m ≥ | 2.5 | 4.5 | 6.5 | 8.0 | 9.5 | 11.0 | 12.5 | 14.0 | 16.0 | 19.0 | 25.0 | MD and TD |
5 | Elongation at Break % | 25~100 | |||||||||||
6 | CBR Mullen Burst Strength KN≥ | 0.3 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 | 2.1 | 2.4 | 2.7 | 3.2 | 4.0 |
|
7 | Sieve Size O90 mm | 0.07~0.2 |
| ||||||||||
8 | Vertical Permeability | K× (10-1~10-3) | k=1.0-9.9 | ||||||||||
9 | Tear Strength KN≥ | 0.08 | 0.12 | 0.16 | 0.20 | 0.24 | 0.28 | 0.33 | 0.38 | 0.42 | 0.46 | 0.6 | MD and TD |
