Help Center2-6m PET Needle Punched Geotextile
Related Products
-
Bridge Abutments GeotextileNegotiableMOQ: 1000 Square Meters -
Railroad Separation Geotextile FabricNegotiableMOQ: 1000 Square Meters
-
Shoreline Erosion Control GeotextileNegotiableMOQ: 1000 Square Meters
-
Geotextile y GeomembranasNegotiableMOQ: 1000 Square Meters
-
Landfill Geotextile FabricNegotiableMOQ: 1000 Square Meters
Specifications
2-6m PET needle punched geotextileMaterial:PP recycled
Width:1-6m
Weight:100-1200gsm
White/black
2-6m PET needle punched geotextile
2-6m PET needle punched geotextile Introduction:
1. PP/PET short fiber needle punched non woven geotextile.
2. PET continuous filament spunbond needle punched non woven geotextile
The product has the property of anti-aging, high strength, good flexibility and permeability, filtration, isolation and easy construction etc.
It is widely used in areas of the railway, highway, sport venue,dyke,water project construction, tunnel,sea beach,inning...
Packing size:Width:2-6m, Length:50-100m
2-6m PET needle punched geotextile Feature:
1. High intensity, strong penetration resistance;
2. Resistant to acid and alkaline, corrosion and aging;
3. Excellent permeability and filterability;
4. Low cost, favorable price and convinent construction
2-6m PET needle punched geotextile Application:
1.Filtration :
It can be the filtration layer of the dykes, river canal, seacoast, concrete slope, retaining walls. At the same time of preventing the clay granule from passing, it allows the water and the gas pass through freely.
2.Separation :
The isolation of the railway dregs and the roadbed, roadbed and the soft base, surface of the airdrome and parking lot and the groundsill, different dam materials. It isolates the soil and the gravel of two kinds different granule pathway from the groundsill or other buildings.
3.Reinforcement/Roofing :
The highway, railway, soil-stone dam, breakwater, airport and backfill soil of retaining wall, slope protection, etc in which distributes the earth stress, prevents the side-displacement of the earth body and improves the earth-body stability. Also, used as a waterproofing substrate for roofing industries
4.Protection :
It prevents the bank from being washed out, protects the bank and the bottom, prevents the water and soil from being washed away
2-6m PET needle punched geotextile Index:
Item |
Specification |
||||||||
100 |
150 |
200 |
300 |
400 |
500 |
600 |
800 |
1000 |
|
|
Nominal Breaking strength,KN/M
|
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
|
Breaking strength,MD/CD,KN/M≥
|
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
|
Elongation at break,%
|
40-80 |
||||||||
|
CBR Mullen Burst Strength,KN≥
|
0.8 |
1.6 |
1.9 |
2.9 |
3.9 |
5.3 |
6.4 |
7.9 |
8.5 |
|
Tear strength,KN≥
|
0.14 |
0.21 |
0.28 |
0.42 |
0.56 |
0.70 |
0.82 |
1.10 |
1.25 |
|
Sieve size O90(O95),mm
|
0.05-0.20 |
||||||||
Vertical Permeability Coefficient, cm/s |
K×(10-1-10-3), K=1.0-9.9 |
||||||||
Thickness,mm≥ |
0.8 |
1.2 |
1.6 |
2.2 |
2.8 |
3.4 |
4.2 |
5.5 |
6.8 |
Width Variation,% |
-0.5 |
||||||||
Weight Variation,% |
-5 |
||||||||
Remarks |
We also can produce almost double Strength higher than the chart show |
||||||||
