Specifications
geotextile for floats path1.High strength Geotextile Fabric
2.Good permeable Geotextile Fabric
3.Geotextile Fab
geotextile for floats path
geotextile for floats path Introduction:
1.Our geotextile can be made of polyproplyene(PP) or polyester(PET) .
2.The weight is available from 100g/m2 to 1200g/m2 and the width from 1m to 8m,
3. two kinds of processing technical to select: needle punched and thermally bonded,long fiber or short fiber.
4. All kinds of colors are available.
5.It is widely known as earthwork material and industry fabric, used in the areas of railway, highway, water comservancy, dam, tunnel, subway, environment protection and so on.
geotextile for floats path Usage:
1, Water conservancy project dams and slope of filtration , channel isolation, impervious ;
2, Highways , railways, airport runways based isolation, filtration , drainage, slopes, retaining walls and pavement reinforcement, drainage ;
3, Port engineering soft ground , beach causeway , harbor piers and breakwaters reinforcement, drainage ;
4, Polyester filament geotextile has been widely used in the field of infrastructure construction , and gradually be applied to a wider range of fields.
geotextile for floats path Technical parameters:
NO. |
Item |
Specification |
Note |
|||||||||||
100 |
150 |
200 |
250g |
300 |
350g |
400 |
450 |
500 |
600 |
800 |
||||
1 |
Weight Variation% |
-8 |
-8 |
-8 |
-8 |
-7 |
-7 |
-7 |
-7 |
-6 |
-6 |
-6 |
|
|
2 |
Thickness mm |
0.9 |
1.3 |
1.7 |
2.1 |
2.4 |
2.7 |
3.0 |
3.3 |
3.6 |
4.1 |
5.0 |
||
3 |
Width Variation % |
-0.5 |
||||||||||||
4 |
Breaking Strength KN/m |
2.5 |
4.5 |
6.5 |
8.0 |
9.5 |
11.0 |
12.5 |
14.0 |
16.0 |
19.0 |
25.0 |
|
|
5 |
Elongation at Break % |
25~100 |
||||||||||||
6 |
CBR Mullen Burst Strength |
0.3 |
0.6 |
0.9 |
1.2 |
1.5 |
1.8 |
2.1 |
2.4 |
2.7 |
3.2 |
4.0 |
|
|
7 |
Sieve Size O90 mm |
0.07~0.2 |
|
|||||||||||
8 |
Vertical Permeability Coefficient cm/s |
K× (10-1~10-3)
|
k=1.0-9.9 |
|||||||||||
9 |
Tear Strength KN |
0.08 |
0.12 |
0.16 |
0.20 |
0.24 |
0.28 |
0.33 |
0.38 |
0.42 |
0.46 |
0.6 |
MD and TD |
|
