Home > Products > Staple Fiber Needle Punched Nonwoven Geotextile > geotextile driveway fabric
geotextile driveway fabric
- 10000 Square Meter / Square Meters per Month
- qingdao
- T/T D/P D/A Credit Card PayPal
- 10mm thick 13kg flexible composite cement blanket with compressive strength of 40Mpa and flexural strength of 20Mpa
- Cement blanket 10mm thick, weighing 12.5kg, 2 meters wide, and 50 meters long
- Mesh interwoven drainage board, plastic geotextile mat, seepage drainage 30mm thick
- 3cm thick mesh interwoven drainage board plastic geotextile mat
- Polypropylene Geotextile 800g polyester long fiber geotextile white
- 6000g natural nanogel coated bentonite waterproof blanket for underground garage of Grand Hotel
Product Details
Place of Origin: | Shandong, China | Brand Name: | starring | Model Number: | geotextile |
Geotextile Type: | Non-Woven Geotextiles |
Product Description
Specifications
geotextile driveway fabricMaterial:PP recycled
Width:1-6m
Weight:100-1200gsm
White/black
geotextile driveway fabric
geotextile driveway fabric Introduction:
1. PP/PET short fiber needle punched non woven geotextile.
2. PET continuous filament spunbond needle punched non woven geotextile
The product has the property of anti-aging, high strength, good flexibility and permeability, filtration, isolation and easy construction etc.
It is widely used in areas of the railway, highway, sport venue,dyke,water project construction, tunnel,sea beach,inning...
Packing size:Width:2-6m, Length:50-100m
geotextile driveway fabric Feature:
1. High intensity, strong penetration resistance;
2. Resistant to acid and alkaline, corrosion and aging;
3. Excellent permeability and filterability;
4. Low cost, favorable price and convinent construction
geotextile driveway fabric Application:
1.isolation
The use of geotextile different physical properties (particle size, distribution, density and thickness, etc.) materials (such as soil and sand, sand and gravel soil, soil and concrete, etc.) for isolation.
So that two or more materials are not loss of interand nonhybrid, to maintain the overall structure of the material and functions of the structures is to strengthen the load bearing capacity.
2.filter
When the water from fine materials into the soil layers of rough material, the use of acupuncture geogextile good air and water permeability, so that the water flow through, and effective
interception soil particles, spinning, the small stone so as to maintain the stability of the soil and water projects.
3.Drainage
Acupuncture geotextile is a good hydraulic material, which can from a soil internal drainage channel, soil structure and excess liquid gas emissions.
4.Reinforced
Acupuncture use of geotextile to enhance soil and the tensile strength of the anti-deformation ability to increase the stability of the building structure in order to improve the quality of the soil.
5.Protection
Will focus on effective stress proliferation, transfer or broken down by external force to prevent the soil and damage.
6. Closed
Acupuncture geotextile and other materials (primarily asphalt or plastic film) with the formation of impermeable layer of insulation layer. (Mainly used for road resurfacing
layer. (Mainly used for road resurfacing
geotextile driveway fabric Index:
Item | Specification | ||||||||
100 | 150 | 200 | 300 | 400 | 500 | 600 | 800 | 1000 | |
Nominal Breaking strength,KN/M
| 4.5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 |
Breaking strength,MD/CD,KN/M≥
| 4.5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 |
Elongation at break,%
| 40-80 | ||||||||
CBR Mullen Burst Strength,KN≥
| 0.8 | 1.6 | 1.9 | 2.9 | 3.9 | 5.3 | 6.4 | 7.9 | 8.5 |
Tear strength,KN≥
| 0.14 | 0.21 | 0.28 | 0.42 | 0.56 | 0.70 | 0.82 | 1.10 | 1.25 |
Sieve size O90(O95),mm
| 0.05-0.20 | ||||||||
Vertical Permeability Coefficient, cm/s | K×(10-1-10-3), K=1.0-9.9 | ||||||||
Thickness,mm≥ | 0.8 | 1.2 | 1.6 | 2.2 | 2.8 | 3.4 | 4.2 | 5.5 | 6.8 |
Width Variation,% |
-0.5 | ||||||||
Weight Variation,% | -5 | ||||||||
Remarks | We also can produce almost double Strength higher than the chart show |
