Specifications
Geomembrane CushionMaterial:virgin or recycled
Weight: 100G/M2-1200G/M2
Width: 1-6m
Longth:50m
Geomembrane Cushion
Geomembrane Cushion Introduction:
Geotextile are made from 100% staple polyester and polypropylene needle-punched filter fabric. They have excellent waterflow rates and drainage for the filtration of soil fines. Non-woven Geotextiles have a variety of uses, some of which include trench drains and wrapping perforated pipe to protect against erosion and being combined with geomembranes to provide protective cushioning. Other uses include tensile reinforcement, filtration, and separation for roads, roofs, railroads, ponds, dams, trenches, landfills, protection for shoreline and membrane liners, sub-grade stabilization, erosion control, and many other civil engineering and construction uses. This product is resistant to tears and punctures, soil chemicals, UV rays, mildew, and freeze thaw.
Geomembrane Cushion Feature:
1.Good water permeability
2.Corrosion resistance
3.Microbial resistant
4.Good permeability
5.Good water conductivity
6.High tensile strength
7.Strong resistance to deformation
8.The mesh is not easily blocked
Geomembrane Cushion Application:
|
Industry |
geotextile fabric, water proofing fabric, filter material, roadbed cloth, bank protecting cloth, insulation materials, cement bag, landfill,controlling erosion , ground reinforcement,soil seperation, ground drainage,controlling weeds, structure drainage,etc |
Garment |
Shoulder pads ,face mask ,shoes cover /insoles, chest piece fabric, chest piece fabric,bra fabric,sleeve article cage, cap/hat/bag lining, ,etc
|
|
leg non-slip pad,etc |
|
|
Decotation |
lining of luggage bags,handicraft , festival decoration, automobile interior,roof lining fabric ,etc |
Agriculture |
Geotextile ,protection material ,grow bags , felt pots, filter bag,etc
|
Geomembrane Cushion Specification:
NO. |
Item Value |
Specification |
Note |
||||||||||
|
100 g |
150g |
200g |
250 g |
300 g |
350 g |
400 g |
450 g |
500 g |
600 g |
800 g |
||
1 |
Weight Variation% |
-8 |
-8 |
-8 |
-8 |
-7 |
-7 |
-7 |
-7 |
-6 |
-6 |
-6 |
|
2 |
Thickness mm≥ |
0.9 |
1.3 |
1.7 |
2.1 |
2.4 |
2.7 |
3.0 |
3.3 |
3.6 |
4.1 |
5.0 |
|
3 |
Width Variation % |
-0.5 |
|||||||||||
4 |
Breaking Strength KN/m ≥ |
2.5 |
4.5 |
6.5 |
8.0 |
9.5 |
11.0 |
12.5 |
14.0 |
16.0 |
19.0 |
25.0 |
MD and TD |
5 |
Elongation at Break % |
25~100 |
|||||||||||
6 |
CBR Mullen Burst Strength KN≥ |
0.3 |
0.6 |
0.9 |
1.2 |
1.5 |
1.8 |
2.1 |
2.4 |
2.7 |
3.2 |
4.0 |
|
7 |
Sieve Size O90 mm |
0.07~0.2 |
|
||||||||||
8 |
Vertical Permeability |
K× (10-1~10-3) |
k=1.0-9.9 |
||||||||||
9 |
Tear Strength KN≥ |
0.08 |
0.12 |
0.16 |
0.20 |
0.24 |
0.28 |
0.33 |
0.38 |
0.42 |
0.46 |
0.6 |
MD and TD |
Pls feel free to contact us:
