Specifications
Geotextile nonwoven filter fabricMaterial:PP recycled
Width:1-6m
Weight:100-1200gsm
White/black
Geotextile nonwoven filter fabric
Geotextile nonwoven filter fabric Introduction:
Non woven Geotextiles Fabrics are probably the most commonly known geotextiles. Nonwoven polypropylene fabric, which has a felt-like consistency, combines strength and flow ability. Available in varying weights and thicknesses, the fabrics are strong but permeable, allowing for varied uses. Nonwoven fabrics commonly are used as a separator between subsoils and rock riprap, and they also are used to separate soils and sized stone in many ground-level and subsurface drainage applications. Nonwoven Geotextile Fabrics have a random, three dimensional pore structure and are highly water permeable, as is necessary in many geotextile end uses. A wide range of fabric weights ranging from 3.1oz. to over 16 oz. is offered to meet the requirements of various Non-woven applications. Custom sizes are available with all of our Woven and Non Woven Geotextile Fabrics.
Geotextile nonwoven filter fabric Feature:
1. High intensity, strong penetration resistance;
2. Resistant to acid and alkaline, corrosion and aging;
3. Excellent permeability and filterability;
4. Low cost, favorable price and convinent construction
Geotextile nonwoven filter fabric Application:
- Filtration of soils in drainage applications by retaining soil particles while allowing for the free flow of water
- Separation and stabilization in road and railway construction
- Prevention of soil movement in erosion control measures
- Cushioning and protection in many containment projects
Geotextile nonwoven filter fabric Index:
Item |
Specification |
||||||||
100 |
150 |
200 |
300 |
400 |
500 |
600 |
800 |
1000 |
|
|
Nominal Breaking strength,KN/M
|
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
|
Breaking strength,MD/CD,KN/M≥
|
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
|
Elongation at break,%
|
40-80 |
||||||||
|
CBR Mullen Burst Strength,KN≥
|
0.8 |
1.6 |
1.9 |
2.9 |
3.9 |
5.3 |
6.4 |
7.9 |
8.5 |
|
Tear strength,KN≥
|
0.14 |
0.21 |
0.28 |
0.42 |
0.56 |
0.70 |
0.82 |
1.10 |
1.25 |
|
Sieve size O90(O95),mm
|
0.05-0.20 |
||||||||
Vertical Permeability Coefficient, cm/s |
K×(10-1-10-3), K=1.0-9.9 |
||||||||
Thickness,mm≥ |
0.8 |
1.2 |
1.6 |
2.2 |
2.8 |
3.4 |
4.2 |
5.5 |
6.8 |
Width Variation,% |
-0.5 |
||||||||
Weight Variation,% |
-5 |
||||||||
Remarks |
We also can produce almost double Strength higher than the chart show |
||||||||
