320g geotextile polyester
320g geotextile polyester Introduction:
320g geotextile polyester Feature:
Geotextile has good air and water permeability to let water flow through it so as to effectively control sandrock running-down.
Geotextile has good water transmissibility, it can form drainage channels inside soil mass to drain redundant liquid and air out of the soil mass.
Geotextile helps to enhance the soil mass' tensile strength and non-deformability and structural stability so as to improve soil mass quality.
It can effectively make the concentrated stress diffuse, transfer or decompound, and prevent the soil mass against the destruction of outside force.
It can prevent the mixture of sandstone, soil mass and concrete of upper and lower layers.
Its mesh is hard to jam by virtue of the compliancy and motility of the reticulation formed by indefinite form fibrous tissue.
High water permeability-it can keep good water permeability even in the pressure of soil and water.
Corrosion resistant-it is made from polypropylene fiber or terylene or other chemical fiber, featuring resistance to acid and alkali and oxidation, non-corroding, no worm-eaten.
Easy construction-low weight, easy operation, simple construction
320g geotextile polyester Application:
1.Filtration The filtration layer of the dykes, river canal, seacoast, concrete slope, retaining walls. At the same time of preventing the clay granule from passing, it allows the water and the gas pass through freely.
2 Separation: The isolation of the railway dregs and the roadbed, roadbed and the soft base, surface of the airdrome and parking lot and the groundsill, different dam materials. It isolates the soil and the gravel of two kinds different granule pathway from the groundsill or other buildings.
3 Adding muscle: The highway, railway, soilstone dam, breakwater, airport, backfill soil of retaining wall, slope protection, etc in which distributes the earth stress, prevents the side-displacement of the earth body and improves the earth body stability.
4 Protection It prevents the bank from being washed out, protects the bank and the bottom, prevents the water and soil from beined away.
320g geotextile polyester index:
Item |
Specification |
||||||||
100 |
150 |
200 |
300 |
400 |
500 |
600 |
800 |
1000 |
|
|
Nominal Breaking strength,KN/M
|
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
|
Breaking strength,MD/CD,KN/M≥
|
4.5 |
7.5 |
10 |
15 |
20 |
25 |
30 |
40 |
50 |
|
Elongation at break,%
|
40-80 |
||||||||
|
CBR Mullen Burst Strength,KN≥
|
0.8 |
1.6 |
1.9 |
2.9 |
3.9 |
5.3 |
6.4 |
7.9 |
8.5 |
|
Tear strength,KN≥
|
0.14 |
0.21 |
0.28 |
0.42 |
0.56 |
0.70 |
0.82 |
1.10 |
1.25 |
|
Sieve size O90(O95),mm
|
0.05-0.20 |
||||||||
Vertical Permeability Coefficient, cm/s |
K×(10-1-10-3), K=1.0-9.9 |
||||||||
Thickness,mm≥ |
0.8 |
1.2 |
1.6 |
2.2 |
2.8 |
3.4 |
4.2 |
5.5 |
6.8 |
Width Variation,% |
-0.5 |
||||||||
Weight Variation,% |
-5 |
||||||||
Remarks |
We also can produce almost double Strength higher than the chart show |
||||||||
