Specifications
Geotextile used with geomembraneMaterial:PP/PET
Width:1-6m
Weight:100-1200gsm
anti-aging,anti-acid and alkal
Geotextile used with geomembrane
Geotextile used with geomembrane Introduction:
Geotextiles are permeable nonwoven fabrics used to separate,filter,reinforce, protect or drain.Geotextiles allow filtration or separation of granular layers in roads and rail applications,used to protect membranes in landfill applications,used in coastal defence applications and used in landscaping to protect surfaces and structures from weeds and root growth.
Geotextiles are availabel as woven and non-woven .As liner protection, against physical damage, the non wovens are normally the answer.They are made up of fibers of polyester or polypropylene in random directions and punched together by needles during the manufacturing process.Geotextiles are commenly used to separate layers like clay and drainage and to protect liner from damage
Geotextile used with geomembrane Feature:
- Mass per unit areas range from 100g to 800g/m2 to guarantee an available product for every application (heavier products may be available by special order)
- Superior chemical resistance in even the most aggressive environmental applications
- Continuous long fibers needle punched together to form a sturdy fabric capable of withstanding construction installation stresses
- Contains additives for maximum UV resistance
Geotextile used with geomembrane Application:
Used in the project of highway, railway, dam and reclamation for anti-filtering, isolating and water drainage, maintenance.
Decoration: wall decoration cloth, floor leather base cloth and electrostatic flocking fabric
Agriculture: agricultural harvest protective cloth, crop and plant protection, weed strip
Waterproof material: high-grade breathable waterproof fabric
Industrial applications: filter materials, insulation materials, electrical appliances, reinforcement materials and supporting materials
Car decoration materials
Geotextile used with geomembrane specification:
2-8m Width, 50-100m length (or according to client's requirements
Geotextile used with geomembrane Index:
|
Density |
Thickness |
Breaking Strength |
Elongation of Fracture |
Tearing Strength |
CBR Bursting Strength |
Vertical Penetration Parameter |
Equivalent Aperture |
|
g/m2 |
mm |
KN/m |
% |
KN |
KN |
cm/s |
O 95 mm |
|
100 |
0.9 |
2.5 |
25 ~ 100 |
0.08 |
0.3 |
K x (10 -1 ~ 10 -3) (K = 1.0 ~ 9.9) |
0.07 ~ 0.2 |
|
150 |
1.3 |
4.5 |
0.12 |
0.6 |
|||
|
200 |
1.7 |
6.5 |
0.16 |
0.9 |
|||
|
250 |
2.1 |
8.0 |
0.20 |
1.2 |
|||
|
300 |
2.4 |
9.5 |
0.24 |
1.5 |
|||
|
350 |
2.7 |
11.0 |
0.28 |
1.8 |
|||
|
400 |
3.0 |
12.5 |
0.33 |
2.1 |
|||
|
450 |
3.3 |
14.0 |
0.38 |
2.4 |
|||
|
500 |
3.6 |
16.0 |
0.42 |
2.7 |
|||
|
600 |
4.1 |
19.0 |
0.46 |
3.2 |
|||
|
800 |
5.0 |
25.0 |
0.60 |
4.0 |
