Specifications
150GSM Geotextile short fiber fabricMaterial:PP/PET
Width:1-6m
Weight:100-1200gsm
anti-aging,anti-acid and alkal
150GSM Geotextile short fiber fabric
150GSM Geotextile short fiber fabric Introduction:
Geotextile Non-Woven sheet China can be made of polypropylene (PP) or polyester(PET), The weight is available from 100G/M2 to 1200G/M2 and the width from 1m to 8m, Two kinds of processing technical to select: Needle punched and thermally bonded. Long fiber or short fiber. All kinds of colors are available. Our annual production ability is 20 million square meters.
Geotextile Non-Woven sheet China is widely known as earthwork material and industry fabric, used in the areas of railway, highway, water conservancy, dam, tunnel, subway, environment protection and so on.
150GSM Geotextile short fiber fabric Feature:
- Engineered to provide high strength and high elongation at break to ensure excellent resistance to damage during construction.
- Manufactured from high tenacity UV stabilised virgin polypropylene or polyester fibers which have been heavily drawn to ensure excellent long term durability in all soil types.
- Manufactured using a randomly orientated web to proide completely isotropic properties,ensuring that high strength is not limited to a single direction.
- Excellent uniformity with high permeability and low pore size for soil filtration.
- Supplied to a maximum width of 6.5mts,ensuring minimum waste over large construction areas.
- 100% polypropylene or polyester staple fibers ,needle punched and random network formation.
- UV and rot resistant and biological degradation resistant
150GSM Geotextile short fiber fabric Application:
Used in the project of highway, railway, dam and reclamation for anti-filtering, isolating and water drainage, maintenance.
Decoration: wall decoration cloth, floor leather base cloth and electrostatic flocking fabric
Agriculture: agricultural harvest protective cloth, crop and plant protection, weed strip
Waterproof material: high-grade breathable waterproof fabric
Industrial applications: filter materials, insulation materials, electrical appliances, reinforcement materials and supporting materials
Car decoration materials
150GSM Geotextile short fiber fabric specification:
2-8m Width, 50-100m length (or according to client's requirements
150GSM Geotextile short fiber fabric Parameter Index:
| Density | Thickness | Breaking Strength | Elongation of Fracture | Tearing Strength | CBR Bursting Strength | Vertical Penetration Parameter | Equivalent Aperture |
| g/m2 | mm | KN/m | % | KN | KN | cm/s | O 95 mm |
| 100 | 0.9 | 2.5 | 25 ~ 100 | 0.08 | 0.3 | K x (10 -1 ~ 10 -3) (K = 1.0 ~ 9.9) | 0.07 ~ 0.2 |
| 150 | 1.3 | 4.5 | 0.12 | 0.6 | |||
| 200 | 1.7 | 6.5 | 0.16 | 0.9 | |||
| 250 | 2.1 | 8.0 | 0.20 | 1.2 | |||
| 300 | 2.4 | 9.5 | 0.24 | 1.5 | |||
| 350 | 2.7 | 11.0 | 0.28 | 1.8 | |||
| 400 | 3.0 | 12.5 | 0.33 | 2.1 | |||
| 450 | 3.3 | 14.0 | 0.38 | 2.4 | |||
| 500 | 3.6 | 16.0 | 0.42 | 2.7 | |||
| 600 | 4.1 | 19.0 | 0.46 | 3.2 | |||
| 800 | 5.0 | 25.0 | 0.60 | 4.0 |
