Home > Products > Staple Fiber Needle Punched Nonwoven Geotextile > Roadbed Geotextile fabric
Roadbed Geotextile fabric
- 10000 Square Meter / Square Meters per Month
- qingdao
- T/T D/P D/A Credit Card PayPal
- 10mm thick 13kg flexible composite cement blanket with compressive strength of 40Mpa and flexural strength of 20Mpa
- Cement blanket 10mm thick, weighing 12.5kg, 2 meters wide, and 50 meters long
- Mesh interwoven drainage board, plastic geotextile mat, seepage drainage 30mm thick
- 3cm thick mesh interwoven drainage board plastic geotextile mat
- Polypropylene Geotextile 800g polyester long fiber geotextile white
- 6000g natural nanogel coated bentonite waterproof blanket for underground garage of Grand Hotel
Product Details
Place of Origin: | Shandong, China | Brand Name: | starring | Model Number: | geotextile |
Geotextile Type: | Non-Woven Geotextiles |
Product Description
Specifications
Roadbed Geotextile fabricMaterial:PP/PET
Width:1-6m
Weight:100-1200gsm
anti-aging,anti-acid and alkal
Roadbed Geotextile fabric
Roadbed Geotextile fabric Introduction:
Geotextiles are permeable nonwoven fabrics used to separate,filter,reinforce, protect or drain.Geotextiles allow filtration or separation of granular layers in roads and rail applications,used to protect membranes in landfill applications,used in coastal defence applications and used in landscaping to protect surfaces and structures from weeds and root growth.
Geotextiles are availabel as woven and non-woven .As liner protection, against physical damage, the non wovens are normally the answer.They are made up of fibers of polyester or polypropylene in random directions and punched together by needles during the manufacturing process.Geotextiles are commenly used to separate layers like clay and drainage and to protect liner from damage
Roadbed Geotextile fabric Feature:
- Mass per unit areas range from 100g to 800g/m2 to guarantee an available product for every application (heavier products may be available by special order)
- Superior chemical resistance in even the most aggressive environmental applications
- Continuous long fibers needle punched together to form a sturdy fabric capable of withstanding construction installation stresses
- Contains additives for maximum UV resistance
Roadbed Geotextile fabric Application:
Used in the project of highway, railway, dam and reclamation for anti-filtering, isolating and water drainage, maintenance.
Decoration: wall decoration cloth, floor leather base cloth and electrostatic flocking fabric
Agriculture: agricultural harvest protective cloth, crop and plant protection, weed strip
Waterproof material: high-grade breathable waterproof fabric
Industrial applications: filter materials, insulation materials, electrical appliances, reinforcement materials and supporting materials
Car decoration materials
Roadbed Geotextile fabric specification:
2-8m Width, 50-100m length (or according to client's requirements
Roadbed Geotextile fabric Index:
Density | Thickness | Breaking Strength | Elongation of Fracture | Tearing Strength | CBR Bursting Strength | Vertical Penetration Parameter | Equivalent Aperture |
g/m2 | mm | KN/m | % | KN | KN | cm/s | O 95 mm |
100 | 0.9 | 2.5 | 25 ~ 100 | 0.08 | 0.3 | K x (10 -1 ~ 10 -3) (K = 1.0 ~ 9.9) | 0.07 ~ 0.2 |
150 | 1.3 | 4.5 | 0.12 | 0.6 | |||
200 | 1.7 | 6.5 | 0.16 | 0.9 | |||
250 | 2.1 | 8.0 | 0.20 | 1.2 | |||
300 | 2.4 | 9.5 | 0.24 | 1.5 | |||
350 | 2.7 | 11.0 | 0.28 | 1.8 | |||
400 | 3.0 | 12.5 | 0.33 | 2.1 | |||
450 | 3.3 | 14.0 | 0.38 | 2.4 | |||
500 | 3.6 | 16.0 | 0.42 | 2.7 | |||
600 | 4.1 | 19.0 | 0.46 | 3.2 | |||
800 | 5.0 | 25.0 | 0.60 | 4.0 |
