10/100M Fast Ethernet Fiber Media Converter  Fast Ethernet to SC media converter SC fiber port to Ethernet converter

Product Introduction

DLX-850 series 10/100M  Ethernet Fiber Media Converter is a kind of media converter with the  function of photo electricity  switchover between 10Base-T twisted-pair and 10Base-FL optical cable  or between 100Base-TX twisted-pair and 100Base-FX optical cable. It  can extend the transmission distance of conventional 10M Ethernet or  100M Fast Ethernet to 100KM via the Fast Ethernet Fiber-optical  Line. It can realize the connection between terminal and server,  repeaters, hub, Exchanger or terminal easily. Realizes plug and play  in the condition of without setup and drive.

Product Feature

●      Capable of  filtering broadcast, automatic recognizing and modifying address  with store-and-transmission operational mechanism

●      Fully  compatible with IEEEE802.3, IEEE802.3U, IEEEE802.3X, IEEE802.1d

●      Supports  full duplex flow control or half duplex back pressure flow control

●       Auto-negotiation for 10/100M and the bandwidth can be up to  200Mbps(full-duplex)

●      Advanced  optical and electronic integration mechanism can supports good optic  characteristic and electrical characteristic, and can ensure the  high quality and excellent reliability of data transmit

●      Supports  remote port management function via diagnostic and monitoring LEDs  for the status of power, FX link/ACT, TX link/ACT

●      Supply one  RJ-45 electrical port

●       Support LFP function Optional

●       Auto-negotiate to NIC/HUB and MDI/MDI-X

●      Optional  power: Inner power supply or External power supply

●      Average  working time of fault free is more than 50,000hours,meet the  standard of telecommunication operation

Technologies reference

●      Operating  temperature: 0℃-50℃

●      Storage  temperature: -40℃-70℃

●      Environment  humidity: 5-90%(non-condensing)

●      Power  parameters: 100V~260V AC  (Inner power supply)  or 5V DC (External power supply)

●      Dimension:

Inner power supply: 135mm x  85mm x 25mm

External power supply:  95mm x 70mm x 25mm
