Characteristics of new technology of floral foam making equipment :
1.Our company adopts solid para-formaldehyde synthesis technology, solving the problems of waste water discharge, environment protection, etc.
2.The automatic temperature control system combines electric heating and physical reaction, which improves the production efficiency, reduces the resin production cost. Synthetic resin equipment combined with automatic foaming machine let the stability of the foam(density, strength, water absorption, water retention, PH) come true, and let the foam open porosity rate can reach more than 95%. New technology of the production cost was reduced by 15% than old technology.
3.The whole production line includes resin synthesis equipment, floral foam auto-machine, foaming mould, vertical cutting machine and printing machine, etc.
1000L Electric heating Reaction Still of making phenolic resin
This equipment adopts the material:304L、Q235 :
(1) Energy saving: the production of 700 kg resin used electric 50 RMB, don't need to be heated in the process of production, It was synthesized by chemical physics, compared with other production of foam equipment greatly reduces the cost of production.
(2 ) Environmental protection: no sewage,no waste emissions;
(3) Efficient: 1000 l reactor can produce 700 kg resin, production time 4 hours
(4) the total power configuration: 22 w, actual use power: 6 kw;
Two- group Automatic foaming machine of foaming
Description: (1) material: 304 L, Q235
(2) energy saving, high efficiency, environmental protection equipment, PLC control
(3) the ability of 15 to 20 seconds to 1 m3 after speed: 2800 revolutions per minute
(4) after installation equipment specification: 5.8 M * 2.6 M * 3.5 M
(5) the total power rating: 26.8 KW, the actual average operating power is about 1.05
Foam Mould of foaming foam
Description: (1) the mold specifications: 1 cubic (can be customized according to customer's requirements)
(2) one mold specifications: inner diameter 1 M * 1 M* 1 M
(3) automatic constant temperature setting, time control systems,
(4) three mold after installation equipment specifications: 5.8 M * 1.6 M * 1.6 M length: 13 M
(5) the total power rating: 24 kw
CNC horizontal cutting machine of foam cutting machine
Description:This equipment is CNC automatic operation, and the vertical cutting machine the staff work together, a woman can operation, ability to work in accordance with the eight hours can cut 2000-2200-8 cm specification foam box bubble.
(1) 8 cm foam cutting specifications;
(2) after the installation equipment specification: 5.6 M * 2.8 M * 2.4 M
(3) the total rated power: 4.5 KW
Vertical cutting machine of foam cutting machine
Description: (1) the peel and cut different shape of the bubble specifications;
(2) after installation equipment specification: 3.6 M * 2.8 M * 2.4 M wide
(3) the total power rating: 1.5 KW
Horizontal pushing printing machine of cutting foam and print logo
Description: (1)23 cm, 11 cm size cutting,
(2) printing (LOGO),
(3) the PH treatment system
(4) after installation equipment specification: 5.8 M * 8.6 M * 1.3 M wide
(5) the total power rating: 0.5 KW
(6) production capacity: 8 hours can produce 1500 cartons of foam.
Characteristics of new technology:
1.Our company adopts solid para-formaldehyde synthesis technology, solving the problems of waste water discharge, environment protection, etc.
2.The automatic temperature control system combines electric heating and physical reaction, which improves the production efficiency, reduces the resin production cost. Synthetic resin equipment combined with automatic foaming machine let the stability of the foam(density, strength, water absorption, water retention, PH) come true, and let the foam open porosity rate can reach more than 95%. New technology of the production cost was reduced by 15% than old technology.
3.The whole production line includes resin synthesis equipment, floral foam auto-machine, foaming mould, vertical cutting machine and printing machine, etc.
1. How much space (square meter) the full line would need to install & run?
The full line would need 1000 square meter at least.
2. How many workers would be required to run the full line?
The line need about 10 people to run.
3. What is the total gross weight of the full line?
Over all weight :about 15t .
4. About installation & first run the line, how you cooperate?
1) We seller will send two technicians to teach the technology in your factory for 15-20 days until the buyer learn it well.
2) If there is any problem of the machine or technology in the future, we seller will send the technician to help the buyer solve all these problem.Also you can talk about your question on chat way, we can try my best to help you solve your question.
5. Can I get free floral foam samples?
YES. We would like to send several samples for your reference if you could afford freight.
