Help CenterSolar Air Conditioner, Solar Duct Air Conditioner, Solar Air Conditioner
Related Products
solar air conditioner, solar duct air conditioner, solar air conditionerconditioningsolar air conditioning system solar cooler energy-saving AC solar(heating) air conditioner ,
use solar heating
collector to collect the solar heating help compressor work so that can
save enginey between 30%-60% than common electric air conditioner
Product Description
solar air-conditioner ,energy-saving air conditioner,solar cooler ,solar air conditioning, solar air conditioning system,air conditionersolar air conditioning ,solar air conditioning system solar cooler energy-saving AC solar(heating) air conditioner ,
use solar heating
collector to collect the solar heating help compressor work so that can
save enginey between 30%-60% than common electric air conditioner
Product Description
| Model No. | TKF(R)-72NW | TKF(R)-100NW | TKF(R)-120NW | TKF(R)140NW | ||
| Power Supply220-240VAC, 1/3PH, 50Hz | ||||||
| Performance | ||||||
| Capacity | Cooling | Btu/h | 24000 | 36000 | 41000 | 48000 |
| W | 7200 | 10000 | 12000 | 14000 | ||
| Heating | Btu/h | 27000+1700 | 40000+1700 | 46000+1700 | 55000+1700 | |
| W | 7900+500 | 12000+500 | 14000+500 | 16000+500 | ||
| Noise | Indoor | dB(A) | ≤55 | ≤58 | ≤58 | ≤58 |
| Outdoor | dB(A) | ≤58 | ≤58 | ≤60 | ≤60 | |
| Air Circulation | m³/h | 1400 | 2400 | 2400 | 2400 | |
| Static Pressure | Mpa | 70 | 80 | 80 | 80 | |
| Suitable Area | m² | 30~48 | 42~67 | 50~80 | 58~93 | |
| EER | W/W | 3.82 | 3.87 | 3.96 | 3.87 | |
| Btu/h/w | 13.03 | 13.2 | 13.51 | 13.2 | ||
| Power Consumption | ||||||
| Power Input | Cooling | W | 1700~1900 | 2400~2640 | 2900~3150 | 3500~3740 |
| Heating | W | 1700~1950+500 | 2470~2650+500 | 2900~3180+500 | 3500~3760+500 | |
| Rated Current | Cooling | A | 7.73~8.64 | 10.91~11.95 | 13.18~14.32 | 15.91~17 |
| Heating | A | 7.73~8.66+2.2 | 11.23~12.05+2.2 | 13.18~14.45+2.2 | 15.91~17.09+22 | |
| Dimensions | ||||||
| Indoor Unit | Net | mm | 1040*775*450 | 1190*775*450 | 1190*775*450 | 1190*775*450 |
| Outdoor Unit | Net | mm | 940*300*755 | 950*355*835 | 950*355*1255 | 950*360*1255 |
| Shipping | mm | 990*400*770 | 1140*460*910 | 1140*460*1340 | 1140*460*1340 | |
| Flat plate collector | Shipping | mm | 650*650*60 | 1200*700*80 | 1200*700*80 | 1200*700*80 |
| Shipping | mm | 730*750*130 | 1400*750*130 | 1400*750*130 | 1400*750*130 | |
| Weight | ||||||
| Indoor Unit | Net/Gross | kg | 42 | 58 | 58 | 58 |
| Outdoor Unit | Net/Gross | kg | 55/58 | 73/76 | 95/100 | 97/102 |
| Solar Collector | Net/Gross | kg | 16/17 | 24/27 | 24/27 | 24/27 |
| Quotation | ||||||
| Freon:R410 | ||||||
,
....
