Automatic Soil CBR Proctor Compactor

Automatic Soil CBR Proctor Compactor thumbnail-1
Automatic Soil CBR Proctor Compactor photo-1
US$ 1,680 - 1,780 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YF
Model Number:
DJ-3A
Contact Supplier Request Quote Chat Now
Shanghai Civil & Road Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name YF
Model Number DJ-3A

 Compactor (hammer in center)



CE certified , conforms with ISO 9001 standard



1. Application:

  • This machine is used to test the relation between water content and dry density of soil by certain compaction power with standard compacttion method, to determin the soil's best water content and related max. dry density, so as to understand the soil's compactability as the basis of caly subgrade compactness control in construction site.
  • The machine is suitable for clay subgrade filling construction design in pavement,  railway, water consevancy and construction.
  • It is a mechantronics apparatus, it's structure performance is in accordance with the compactness testing specimen production requirement for CRB testing and rebound modulus testing completely.



2. Characteristic:

  • Microcomputer control
  • Base plate can be pulled and pushed automatically
  • Strile one hammer in the center
  • Can produce two kinds of spodosol and small stone specimen for 152mm and 100mm
  • Have light compactness and heavy compactness
  • Count, stop and cycle work automatically in operation
  • Reliable result, convenient operation, hammer mark disreibute evenly, good quality specimen. It is suitable for onsite soil test in laboratory.



3. Main Technical Parameter:

  • Heavy compactness testing: hammer 4.5kg, falling height: 450mm
  • Light compactness testing: hammer 2.5kh, falling height: 300mm
  • Suitable specimen cylinder diameter: 100mm & 152mm
  • Hammer head diameter: 50mm
  • hammer bash time: 29 times/minute
  • Motor: 370W 380V 1400r/min
  • Outside size: 1320X400X650mm
  • Weight: approx. 130kg

 4. packing list

   1. equip with hammer 2.5kg and 4.5kg each one set

    2. equip with compaction mould 101.6 and 152.4 mm each one set

    3. voltage : 220V , 50HZ
