Power
Other, Manual
Usage
Other, Determination of shear strength
Specifications
Triaxial Testing machine1.Axial load:30KN
2.Max. Stroke: 50mm
3.Max. confining pressure: 2.5Mpa
30KN Triaxial Testing machine
Application:
To determine the strength and deformation characteristics of the soil specimen. Perform unconsolidated-Unstrained shear test (UU), consolidated-unstrained shear test(CU) and consolidated-drained shear test(CD).
Technical parameters:
1. Specimen size: Φ39.1×80mm ; Φ61.8×125 mm;
2. Axial load: 30KN
3. Lift speed range(mm/min): 0.003, 0.006, 0.008, 0.012, 0.020, 0.030, 0.040, 0.050,
0.060, 0.070, 0.080, 0.090, 0.100, 0.200, 0.300,
4. Max. Stroke: 50mm
5. Max. confining pressure: 2.5Mpa
6. Max. back pressure: 1Mpa
7. Pore water pressure: 0-2Mpa
8. Volume change range: 0-50ml
9. Min. division: 0.1ml
10. Axial displacement range: 0-30mm
11. Displacement rate: 0.001-1mm/min
12.Dimensions:790×610×1290mm(main frame),750×730×1240mm(controller)
