S05-SM ZigBee IP66 Wireless Soil Moisture Sensor
The S05-SM is a soil moisture sensor designed for precision data capturing in agriculture. This wireless device is housed in an IP66 certified casing eliminating the need for wire installation and giving it a high resistance to extreme weather and conditions. The S05-SM is battery powered and has a transmission range of 500m making it suitable for installation out in the fields. This device is also compatible with ZigBee Sentrol Cloud and ZigBee Complete Solution for constant data collection, instant awareness and automated environment control. With this device the environment can be controlled allowing the farmer to maximize utility and better the use of resources and energy which results in a rapid return on investment. This device can function as an ‘end device’ (sensor) as well as router in a ZigBee Tree, Star or MESH system.
Features:
1. High Precision soil moisture sensor
2. Compatible with ZigBee Sentrol Cloud and ZigBee Complete Solution for constant data collection
3. 500m/1640ft wireless transmission range
4. Fitted with UV protection and IP66 Water and dust proofing to protect against the elements
5. Powered by 4 x AA battery with a battery life of 1yr+
6. Rapid return on investment
7. ZigBee HA Profile compliant
Sensing Type |
Soil Moisture |
Sensing Range |
0% - 95% RH |
Measurement Accuracy |
± 5% |
Wireless Protocol |
IEEE 802.15.4 Zigbee2007/PRO HA |
Transmission Range
|
500 meters/ 1640 feet (free space) |
Operating Frequency |
2.4GHz ISM Band |
RF Output Power |
18dBm |
Receiver Sensitivity |
-92dBm |
Ingress Protection |
IP66 |
Power Consumption |
Tx:350mA/ Sleep:5uA |
Power Supply |
DC 6V w/ 4 x AA battery |
| Battery Life | 1 year based on sending data per 10 min |
Operating Environment |
-10°C~45°C / 14°F~113°F |
Transmit Interval |
Set by DIP Switch (1sec. ~ 75min.) |
Network Topology |
Star/ Tree/ Mesh |
Dimensions |
13cm(H) X 5(Φ) cm 5.1inches (H) X 1.9(Φ) inches |
Weight |
265g/ 9.34oZ
|
Certifications |
CE/FCC |
1 Year Warranty. Original Made in Taiwan
