S05-TH ZigBee IP66 Wireless Temperature and Humidity Sensor
The S05-TH is a temperature and humidity sensor designed for precision data capturing in agriculture. This wireless device is housed in an IP66 certified casing eliminating the need for wire and cable installation and giving it a high resistance to extreme weather and conditions. The S05-TH is battery powered and has a transmission range of 500m making it suitable for installation out in the fields. This device is also compatible with ZigBee Sentrol Cloud and ZigBee Complete Solution for constant data collection, instant awareness and automated environment control. This device can function as an ‘end device’ (sensor) as well as router in a ZigBee Tree, Star or MESH system.
Features:
1.High Precision temperature and humidity sensors
2.Compatible with ZigBee Sentrol Cloud and ZigBee Complete Solution for constant data collection
3.500m/1640ft wireless transmission range
4.Fitted with UV protection and IP66 Water and dust proofing to protect against the elements
5.Powered by 4 x AA battery with a battery life of 1yr+
6.ZigBee HA Profile compliant
7.Rapid Return on investment
Sensing Type |
Temperature & Humidity |
Sensing Range |
-10°C ~ 70°C / 14°F ~ 158°F 0 ~ 95% RH |
Measurement Accuracy |
± 0.5°C / 4.5%RH |
Wireless Protocol |
IEEE 802.15.4 Zigbee2007/PRO HA |
Transmission Range |
500 meters/ 1640 feet (free space) |
Operating Frequency |
2.4GHz ISM Band |
RF Output Power |
18dBm |
Receiver Sensitivity |
-92dBm |
Ingress Protection |
IP66 |
Power Consumption |
Tx:350mA/ Sleep:5uA |
Power Supply |
DC 6V w/ 4 x AA battery |
| Battery Life | 1 year based on sending data per 10 min |
Operating Environment |
-10°C ~ 45°C / 14°F ~ 113°F |
Transmit Interval |
Set by DIP Switch (1sec. ~ 75min.) |
Network Topology |
Star/ Tree/ Mesh |
Dimensions |
13(H) X 5(Φ) cm ; 5.1(H) X 1.9(Φ) inches |
Weight |
265g/ 9.34oZ |
Certifications |
CE/FCC |
1 Year Warranty. Original Made in Taiwan
