Outdoor IP66 Wireless Soil Temperature Sensor S05-ST

Outdoor IP66 Wireless Soil Temperature Sensor S05-ST photo-1
Outdoor IP66 Wireless Soil Temperature Sensor S05-ST photo-2
Outdoor IP66 Wireless Soil Temperature Sensor S05-ST photo-3
Outdoor IP66 Wireless Soil Temperature Sensor S05-ST photo-4
Outdoor IP66 Wireless Soil Temperature Sensor S05-ST photo-5
Outdoor IP66 Wireless Soil Temperature Sensor S05-ST photo-6
US$ 130 - 160 MOQ: 1 Piece
Key Specifications
Get Latest Price
Size:
Small
Type:
Other, Wireless Soil Temperature Sensor
Model Number:
S05-ST
Payment & Shipping
Payment Methods:
Port of Shipment:
Taipei Taiwan
Delivery Detail:
Delivery time depends on order quantity.
Size Small
Type Other, Wireless Soil Temperature Sensor
Model Number S05-ST
Place of Origin Taiwan, China
Brand Name NHR

Outdoor IP66 Wireless Soil Temperature Sensor S05-ST



S05-ST ZigBee IP66 Wireless Soil Temp. Sensor



The S05-ST is a soil temperature sensor designed for precision data capturing in agriculture. This wireless device is housed in an IP66 certified casing eliminating the need for wire installation and giving it a high resistance to extreme weather and conditions. The S05-ST is battery powered and has a transmission range of 500m making it suitable for installation out in the fields. This device is also compatible with ZigBee Sentrol Cloud and ZigBee Complete Solution for constant data collection, instant awareness and automated environment control. With this device the environment can be controlled allowing the farmer to maximize utility and better the use of resources and energy which results in a rapid return on investment.This device can function as an ‘end device’ (sensor) as well as router in a ZigBee Tree, Star or MESH system.



Features:

1.     High Precision soil temperature sensor
2.     Compatible with ZigBee Sentrol Cloud and ZigBee Complete Solution for constant data collection, instant awareness
       and automated environment control
3.     500m/1640ft wireless transmission range
4.     Fitted with UV protection and IP66 Water and dust proofing to protect against the elements
5.     Powered by 4 x AA battery with a battery life of 1yr+
6.     ZigBee HA Profile compliant
7.     Rapid Return on investment



Specification:
Sensing TypeSoil Temperature
Sensing Range-40 °C ~ 120°C
Measurement Accuracy± 1°C
Wireless ProtocolIEEE 802.15.4 Zigbee2007/PRO HA
Transmission Range500 meters/ 1640 feet (free space)
Operating Frequency2.4GHz ISM Band
RF Output Power18dBm
Receiver Sensitivity-92dBm
Ingress ProtectionIP66
Power ConsumptionTx:350mA / Sleep:5uA
Power SupplyDC 6V w/ 4 x AA battery
Battery Life1 year based on sending data per 10 min
Operating Environment-10°C ~ 45°C / 14°F ~ 113°F
Transmit IntervalSet by DIP Switch (1sec. ~ 75min.)
Network TopologyStar/ Tree/ Mesh
Dimensions
13(H) X 5(Φ) cm
5.1(H) X 1.9(Φ) inches
Weight265g/ 9.34oZ
CertificationsCE/FCC





1 Year Warranty. Original Made in Taiwan
