AR-3000 2.4Ghz 500mW Indoor AP Router That Can be Used With 1W USB Adapter AOU-2410 or 3G USB Dongle

AR-3000 2.4Ghz 500mW Indoor AP Router That Can be Used With 1W USB Adapter AOU-2410 or 3G USB Dongle thumbnail-1
AR-3000 2.4Ghz 500mW Indoor AP Router That Can be Used With 1W USB Adapter AOU-2410 or 3G USB Dongle thumbnail-2
AR-3000 2.4Ghz 500mW Indoor AP Router That Can be Used With 1W USB Adapter AOU-2410 or 3G USB Dongle thumbnail-3
AR-3000 2.4Ghz 500mW Indoor AP Router That Can be Used With 1W USB Adapter AOU-2410 or 3G USB Dongle thumbnail-4
AR-3000 2.4Ghz 500mW Indoor AP Router That Can be Used With 1W USB Adapter AOU-2410 or 3G USB Dongle thumbnail-5
AR-3000 2.4Ghz 500mW Indoor AP Router That Can be Used With 1W USB Adapter AOU-2410 or 3G USB Dongle thumbnail-6
AR-3000 2.4Ghz 500mW Indoor AP Router That Can be Used With 1W USB Adapter AOU-2410 or 3G USB Dongle photo-1
AR-3000 2.4Ghz 500mW Indoor AP Router That Can be Used With 1W USB Adapter AOU-2410 or 3G USB Dongle photo-2
AR-3000 2.4Ghz 500mW Indoor AP Router That Can be Used With 1W USB Adapter AOU-2410 or 3G USB Dongle photo-3
AR-3000 2.4Ghz 500mW Indoor AP Router That Can be Used With 1W USB Adapter AOU-2410 or 3G USB Dongle photo-4
AR-3000 2.4Ghz 500mW Indoor AP Router That Can be Used With 1W USB Adapter AOU-2410 or 3G USB Dongle photo-5
AR-3000 2.4Ghz 500mW Indoor AP Router That Can be Used With 1W USB Adapter AOU-2410 or 3G USB Dongle photo-6
US$ 90 - 110 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
ALCON
Model Number:
Alcon AR-3000
Contact Supplier Request Quote Chat Now
Dow Technology Electronics Trading Co L.l.c
Payment & Shipping
Payment Methods:
Port of Shipment:
Taipei Taiwan
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Taiwan, China
Brand Name ALCON
Model Number Alcon AR-3000





ALCON AR-3000 2.4Ghz 500mW WiFi Mimo Indoor router that can be used with 1W WiFi USB Adapter Alcon AOU-2410 or 3G USB dongle

Now solution to easy provide wireless service to multiple end users with this.
Support USB adapters  - work with AOU-2410 or 3G USB
Strong security (WEP/WPA/WPA2)
Multi-language web-based management interface
5dBi rubber antenna
Ideal product for indoor application

 High Speed Data Rates : Providing faster data rates of up to 150Mbps and is compatible with legacy 802.11b/g equipment

Advanced Robust Security : Firewall with SPI to protect the internal host from hacker attacks. Wireless security is comprehensive and included WPA/WPA2 PSK

Feature Rich : WDS, Dual SSIDs, Static Routing, QoS and more



High Speed Data Rates : Providing faster data rates of up to 150Mbps and is compatible with legacy 802.11b/g equipment

Advanced Robust Security : Firewall with SPI to protect the internal host from hacker attacks. Wireless security is comprehensive and included WPA/WPA2 PSK

Feature Rich : WDS, Dual SSIDs, Static Routing, QoS and more

Technical Specification

Standard Compliance

IEEE 802.11b/g/n, 802.3 (10Base-T), 802.3u (100Base-TX)

Frequency Band

America/FCC: 2412~2462MHz (11 channels)
Europe CE/ETSI: 2412~2472 (13 channels)
Japan: 2412~2484 (14 channels)

Transmission Power

802.11b: 27dBm ± 2dBm
802.11g: 25dBm ± 2dBm
802.11n: 25dBm ± 2dBm

Transmission Rate

802.11b: 1/2/5.5/11Mbps
802.11g: 6/9/12/18/24/36/48/54Mbps
802.11n (20MHz): up to 72Mbps
802.11n (40MHz): up to 150Mbps

Interfaces

10/100Mbps WAN port x 1
10/100Mbps LAN port x 1
USB port x 1

Sensitivity

11n

20MHz

MCS7: -71     MCS0: -90

40MHz

MCS7: -69     MCS0: -88

11g

54Mbps: -75     6Mbps: -92

11b

11Mbps: -90     1Mbps: -95

Antenna Type

External 5dBi rubber antenna

Security System

WEP / WPS / WPA / WPA2

Wireless Setting

Operation Mode – USB wireless adapter / 3G Dongle / ADSL modem / Bridge

Software/Firmware

Dual SSIDs
Suppressed SSID
Static routing
Access Control by MAC address filter
Support DMZ Host, VPN pass-through, IGMP Proxy
802.11e WMM
Web-based multi-language management interface (English, Traditional Chinese & Simplified Chinese)
SNTP time synchronize
Reset Button

Operation Environment

0 ℃ ~ 40 ℃

Power

DC 12V / 1A adapter AC 100V~240V



Currently Supported 3G Data Cards

Vendor Name

 Model Name Supported

Huawei

 E169G
O
E170
O
E172

O
E176

O
E180
O
E220

O
E270

O
E272

O
Vodafone K3565

O

BandRich
(BandLuxe)

 C100S

O
C120

O
C270

O

Sierra

 Aircard 888U (Aircard 888)
O
Compass 596

O

Option

 ICON 225 (GIO 225)
O
GlobeSurfer iCON 7.2
O

Novatel

 Ovation MC950D
O
U760
O
NU MU-Q101
O
Sony Ericsson MD300
O
ZTE MF626
O
Vodafone K3565-Z
O
Vodafone K3520-Z
O
MF627
O
ASUS T500
O
AKIO 82D
O
PROLiNK PHS100
O





AR-3000 2.4Ghz 500mW Indoor AP Router that can be used with 1W USB Adapter AOU-2410 or 3G USB dongleAR-3000 2.4Ghz 500mW Indoor AP Router that can be used with 1W USB Adapter AOU-2410 or 3G USB dongle
