Plastic LDPE mulching film blowing machine
Plastic LDPE mulching film blowing machine
MODEL |
LD1100 |
LD1300 |
PC-65 |
LD2200 |
LD2500 |
LD2600 |
LD2800 |
|
Max. film lay-flat width(mm ) |
1000 |
1200 |
1500 |
2000 |
2300 |
2500 |
2600 |
Film thickness(mm ) |
0.005~0.008 |
0.006~0.009 |
|||||
Output(kg/h ) |
50 |
55 |
210 |
130 |
180 |
220 |
240 |
Raw material |
Virgin LLDPE, LDPE, LLDPE&LDPE blend compound |
||||||
Screw diameter(mm ) |
45 |
50 |
55/65 |
65 |
75 |
75 |
90 |
Screw L/D ratio |
30 |
30 |
30 |
30 |
30 |
30 |
30 |
|
Max. screw rotation speed(r/min) |
130 |
130 |
130/130 |
130 |
110 |
110 |
100 |
|
Main motor mode |
Frequency—conversion speed--regulating |
||||||
|
Main motor power(KW) |
15 |
18.5 |
30/37 |
37 |
55 |
55 |
75 |
Die structure |
Spiral die, processing in machining center |
||||||
Haul-off & winding speed (m/min ) |
120 |
120 |
120 |
120 |
100 |
80 |
80 |
Total power(KW) |
28 |
32.5 |
72 |
80 |
88 |
105 |
180 |
Overall dimension(m) |
6.2X2.3X5 |
6.4X2.5X5 |
6.6X3X6.8 |
7.5X2.5X7.7 |
7.8X3.2X10.5 |
8X3.5X10.5 |
13X4X19 |
Weight(KG) |
5200 |
5500 |
6500 |
8500 |
16000 |
19500 |
21000 |
Feature:
1. Suitable for produce agriculture film of 100% LLDPE or LLDPE mix with other raw material
2.Adopt the most newly advanced technology as heat flow way, extrude to shape film,special for mulch
air ring.
3. Extruder adopts wavy screw, with oblique barrier and the mixing screw head, stable function, reliable,
high-output and low energy consumption.
4. Has the character of good plasticize, high physical and mechanical performance, strong tear resistance.
5. The die adopts central feeding spiral channel forming technology, machinning centre processed.
Plastic LDPE mulching film blowing machine
Business nature: R&D manufacturer. |
|
|
Trade terms: EXW, FOB, CIF, CFR.
| |
Payment terms: T/T, L/C, One-touch via Alibaba, 30% deposit in advance. | |
|
Packaging: standard stretch film packing.
| |
|
Warranty: 12 months after installation.
| |
|
Shipping: ocean container transportation.
| |
|
Delivery detail: within 90 days after advanced deposit received. |
Runhua Plastic Machinery Co., Ltd is a professional Reputation-based company that deals in manufacturer, exporter and supplier of Blown Film Machine with an extensive range. We have high qualified and dedicated workforce which assures you of on-time delivery of high quality products.
Now especially one of the leading suppliers for agricultural film machine, enjoying advanced technology domestic even international, and many times win the large-scale bidding projects, such as CNPC, SINOPEC, Agricultural Bureau of middle west each provinces etc.
Main products line of Runhua:
12 months' quality guarantee, and we supply top quality and service.
Engineers available to serve for customers overseas.
CONSULTING SERVICE
Different customers have different needs, you could tell us your special requirements, our engineer will design the machine as your require.
INSTALLATION SERVICE
Installation service are available with all new machine purchases. We will provide the technical konwledges to help you installing the machine, so you can put the machine into use as soon as possible.
CLIENT TRAINING SERVICE
We can train your staffs to use your equipment. First, we will trian your staffs use the equipment properly. Second, we will tell them how to use the raw materials to produce the film. Different materials and different proportions will lead to different films. After our training, you staff can produce any films you want.
AFTER-SALE SERVICE
We offer the persistent mantainence service and permenate technical assistance. It's benefit to the prevention of the problems and solveing questions as soon as possibe.
