Product Description:
Products profile: Plastic Pipe - PVC Pipe,(Made In China.)
The complete series of our PVC drainage pipes include rainwater pipes, underground drainage pipes and spiral amortization standpipe, which can extensively fit your requirement for many purposes such as city construction and home decoration.
1. Here are characteristics of our PVC drainage pipe:
(1) Fine physicochemical performance, corrosion resistant, excellent in cushion effect, small fluid resistance, flow rate 30% up compared with cast iron pipes of the same diameter.
(2) It is weather resistant, long performance life, the Construction Ministry Fujian Province experimental unit material shows its service life is 30-50 years, being ideal for building drain and blowdown.
(3) Light and durable, convenient in fixing, greatly speed up progress of works, reduce project cost.
(4) Saving building expenses,greatly reduce the overall costs compared with the traditional cast iron pipes.
The color of the corporation's products are mainly white, with esthetic appearance, brightness, smoothness, inspiring the building internal milieu atmosphere to have a sort of neatness, comfortable fashion.
2. PVC Pipe for water supply / PVC pipe for Waste Discharge:
(1).Building Engineering: Building storm sewer, underground drainage pipe, drainage sewage pipe, ventilation pipe.
(2).Industrial: Drainage pipe can be widely used for chemical, medicine, environmental, etc.
(3).Road engineering: Railway and highway as drainage pipe.
Characteristics
1. Made from new PVC materials, with high quality. Reinforced rigid plastic wire is screwed-inserted into the wall of PVC hoses.Excellent resistance to pressure, external impacts, chemical, gases, light acids and saline water.
2. Various Colors: Green, yellow, red, black, clear etc
3. Diameter and thickness can be as customers' requirements
4. Good flexibility. Non-toxic and odorless.
5. To be light in weight, with good resistance to severe weather conditions and negative pressure.
For reference only:
|
Nominal Dimension |
I.D. (mm) | O.D. (mm) | Length (m) | W.P. (Mpa) | B.P. (Mpa) |
| 5/8'' | 16 | 21 | 50 | -0.1 --- 0.4 | 1.0 |
| 3/4'' | 19 | 25 | 50 | -0.1 --- 0.4 | 1.0 |
| 1'' | 25 | 32 | 50 | -0.1 --- 0.6 | 2.0 |
| 1-1/2'' | 38 | 46 | 50 | -0.1 --- 0.6 | 1.8 |
| 2'' | 51 | 60 | 50 | -0.1 --- 0.6 | 1.8 |
| 2-1/2'' | 64 | 73 | 50 | -0.1 --- 0.5 | 1.5 |
| 3'' | 76 | 86 | 50 | -0.1 --- 0.4 | 1.2 |
| 4'' | 102 | 113 | 20 | -0.1 --- 0.3 | 1.0 |
| 5'' | 127 | 139 | 20 | -0.1 --- 0.3 | 1.0 |
For reference only:
| Item Name | Size(inch)*Wall Thickness(mm) | Weight(kg/m) | PCS/BAG |
| ASTM PVC WATER SUPPLY PIPE | 1/2×1.7 | 0.170 | 30 |
| 1/2×1.9 | 0.188 | 30 | |
| 1/2×2.77 | 0.275 | 30 | |
| 3/4×1.9 | 0.250 | 20 | |
| 3/4×2.0 | 0.264 | 20 | |
| 3/4×2.87 | 0.380 | 20 | |
| 1×2.2 | 0.360 | 14 | |
| 1×2.4 | 0.390 | 14 | |
| 1×3.38 | 0.550 | 14 | |
| 1-1/4×2.7 | 0.550 | 10 | |
| 1-1/4×3.56 | 0.685 | 10 | |
| 1-1/2×3.2 | 0.750 | 6 | |
| 1-1/2×3.68 | 0.850 | 6 | |
| 2×3.91 | 1.150 | 4 | |
| 2×42 | 1.220 | 4 | |
| 2-1/2×5.16 | 1.810 | 3 | |
| 3×5.49 | 2.350 | 2 | |
| 3×5.7 | 2.440 | 2 | |
| 4×6.02 | 3.400 | 1 | |
| 4×7.3 | 3.790 | 1 | |
| 6"*7.1 | 5.420 | 1 | |
| ASTM PVC DRAINAGE PIPE | 1-1/4×2.0 | 0.380 | 10 |
| 1-1/2×2.2 | 0.470 | 6 | |
| 2×2.3 | 0.750 | 4 | |
| 3×3.2 | 1.380 | 2 | |
| 4"*3.2 | 1.680 | 1 |
