Home > Packaging & Printing > Package & Conveyance > Packaging Tubes > PA/PP/PE/PVC Flexible Corrugated Electrical Conduit Pipe Info@wanyoumaterial Com
PA/PP/PE/PVC Flexible Corrugated Electrical Conduit Pipe Info@wanyoumaterial Com
US$ 0.1 - 50
MOQ: 10000 Meters
Key Specifications
Get Latest Price
Brand Name:
CZWY
Place of Origin:
China
Model Number:
CZWY-25
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
15 days
Related Products
-
High Quality Plastic Water Pipe-PPR Pipe Info@wanyoumaterial.comUS$ 0.1 - 10MOQ: 10000 Meters -
Plastic Pipe - PVC Drainage Pipe Info@wanyoumaterial.comUS$ 0.1 - 10MOQ: 5000 Meters
-
Plastic Pipe - PVC Tube & Fittings for Water Info@wanyoumaterial.comUS$ 0.1 - 10MOQ: 10000 Meters
-
High Quality Plastic Pipe-PVC Hose Pipe Info@wanyoumaterial.comUS$ 0.1 - 100MOQ: 5000 Meters
-
Exquisite PVC Conduit Pipe Made in China Info@wanyoumaterial.comUS$ 0.1 - 100MOQ: 10000 Meters
Brand Name
CZWY
Place of Origin
China
Model Number
CZWY-25
Material
PVC
Length
as your requirement
Thickness
as your requirement
Specification
as your requirement
Standard
ISO
Product:PA/PP/PE/PVC Flexible Corrugated Electrical Conduit Pipe:
~~~~~~~~~~~~~~~~~~~~~~~Specifications:~~~~~~~~~~~~~~~~~~~~
| Type | ID(inch) | ID*OD(mm) | Pack(m/roll) |
|
CF-7.2 |
3/16" |
4.5X7.2 |
200 |
|
CF-10.0 |
1/4" |
6.5X10.0 |
100 |
|
CF-11.6 |
1/3" |
8.0X11.6 |
100 |
|
CF-13.0 |
3/8" |
10.0X13.0 |
100 |
|
CF-14.0 |
7/16" |
11.0X14.0 |
100 |
|
CF-15.8 |
1/2" |
12.0X15.8 |
100 |
|
CF-18.5 |
9/16" |
14.3X18.5 |
100 |
|
CF-20.0 |
5/8" |
16.0X20.0 |
100 |
|
CF-21.2 |
2/3" |
17.0X21.2 |
100 |
|
CF-25.0 |
3/4" |
20.0X25.0 |
100 |
|
CF-28.5 |
7/8" |
23.0X28.5 |
50 |
|
CF-32.0 |
1" |
25.0X32.0 |
50 |
|
CF-34.5 |
1-1/8" |
29.0X34.5 |
50 |
|
CF-42.5 |
1-3/8" |
36.0X42.5 |
25 |
|
CF-47.0 |
1-1/2" |
38.0X47.0 |
25 |
|
CF-54.5 |
1-7/8" |
48.0X54.5 |
25 |
|
CF-67.2 |
2-1/4" |
56.3X67.2 |
20 |
|
CF-80.0 |
2-5/8" |
66.5X80.0 |
20 |
|
CF-106.0 |
3-1/2" |
91.0X106.0 |
20 |
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
PVC material properties:
Density of 1380 kg/m3
Young's modulus of elasticity (E), 2900-3400 MPa
Tensile strength (sigma t) 50-80 MPa
Elongation @ break 20-40%
Notch test 2-5 kJ/m2
Glass transition temperature of 87 ºC
Melting point is 212 ºC
Vicat B1 85 ºC
Thermal conductivity (lambda) 0.16 W/m.K
Coefficient of thermal expansion (alpha) 8 10-5 / K
The heat capacity (c) 0.9 kJ/(kg · K)
Water absorption (ASTM) 0.04 to 0.4
The refractive index of hard molding product is 1.52 ~ 1.55
Price 0.5 1.25 euro/kg
The melt index of 6-9 g / 10 min
Polyvinyl chloride (PVC) is the biggest characteristic of flame retardant, so is widely used in fire protection applications.But the polyvinyl chloride (PVC) in the process of combustion will release hydrogen chloride and other toxic gases, such as dioxin.
Polyvinyl chloride (PVC) combustion can be divided into two steps.In 240 ºC to 340 ºC before burning decomposition of hydrogen chloride gas and alkadiene contain a double bond, and then in 400-470 ºC carbon burning.
PVC formability:
1. Amorphous materials, hygroscopicity, liquidity is poor, in order to improve the liquidity, prevent bubbles and appropriate drying in advance.
2. Easy to decompose, especially at high temperature in contact with the steel and copper are more likely to break down decomposition temperature (200 degrees c).Molding temperature range is small, must be strictly controlled temperature for the material.
3. Use of screw injection machine and direct the nozzle aperture should be larger, in case of blind Angle hysteresis material.
4. Mould gating system should be thick, the appropriate gate section, mould should be cooling, mould temperature 30 to 60 degrees, the material temperature 160-190.
Material characteristics:
PVC is one of the largest plastic products production in the world, cheap, wide application, polyvinyl chloride (PVC) resin as white or light yellow powder.According to the different USES can join different additives, PVC plastic can present different physical properties and mechanical properties.Add the right amount of plasticizer in PVC resin, can be made into a variety of hard, soft and transparent products.
The density of pure PVC is 1.4 g/cm3, joined the plasticizer and filler of the density of PVC plastics are generally 1.15 2.00 g/cm3.
Hard polyvinyl chloride (PVC) has good tensile, flexural, compressive strength and impact resistance, can be used as structure materials separately.
Soft PVC softness, elongation at break, cold resistance will increase, but the brittleness, hardness, tensile strength decreased.
Polyvinyl chloride (PVC) has good electrical insulation performance, can make low frequency insulation materials, the chemical stability.Due to the poor thermal stability of polyvinyl chloride (PVC), heating for a long time can lead to decompose, release HCL gas, discoloring the polyvinyl chloride (PVC), so its application scope is narrow, with temperatures between 15 ~ 55 ºC in general.
UPVC profile:
UPVC is also called the hard PVC, it is made by the polymerization of vinyl chloride monomer and amorphous thermoplastic resin with certain additives (such as stabilizer, lubricant, filler, etc.).
In addition, using additives used with other resin blend modification method, has the obvious practical value.These have CPVC resin, PE, ABS, EVA, MBS, etc.UPVC high melt viscosity, liquidity is poor, even increase injection pressure and melt temperature, the change of liquidity are slim.
In addition, the forming temperature and the thermal decomposition temperature of the resin is very close, capable of forming temperature range is very narrow, is a kind of difficult to molding material.
