Help CenterStake Cargo Semi Trailer
Related Products
Specifications
Certification:CCC ISO9001.Material:H1250 H850 Q345A
High quality and better price.
STAKE SEMI TRAILER |
|
||||||||||||
DIMENSIONS | |||||||||||||
Tare weight |
8000kg |
Payload |
50000 kg |
||||||||||
Overall length |
13000mm |
Overall width |
2500mm |
Overall height |
1500mm |
||||||||
SPECIFICATION | |||||||||||||
Chassis |
Heavy duty and extra durability designed I beam;opting for high tensile steel Q345,welded by automatic submerged-Aac processes.Top flange 14mm,width140mm;Middle Flange 6mm;bottom flange16mm,width 140mm |
||||||||||||
Axle |
Number |
3 |
Brand |
Fuwa |
Capacity |
13T |
|||||||
Suspension |
Mechanical suspension or air suspension |
|
|||||||||||
Leaf spring |
Leaf spring or air bag |
||||||||||||
Floor |
JOST brand2` bolt-in king pin |
||||||||||||
Tire |
12R22.5 12 pcs |
||||||||||||
Wheel rim |
9.0 |
||||||||||||
Kingpin |
2` bolt-in king pin |
|
|||||||||||
Landing gear |
two-speed,manual operating ,heavy duty landing gear |
||||||||||||
Twist lock |
No |
||||||||||||
Vehicular applications |
Container (20ft.40ft..45ft ) transport |
||||||||||||
Drawing |
Including |
||||||||||||
Braking system |
WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks |
||||||||||||
Paiting |
Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint |
|
|||||||||||
Accessories |
One standard tool box |
||||||||||||
