Specifications
1, Genuine spare parts;2,We are factory, not sale company;
3, Have 60 years history;
4, Quality products and best services
Factory Outlook
Certificate:
Production line:
Products Specifications:
Dimension:
Total length: 12550mm
Width: 2495mm
Height: 2940mm
Body dimension:
Length: 12260mm
Width: 2300mm
Height: 600mm
King pin location: one position on 1055mm from the front face of the front bolster
Fifth wheel height: 1200mm with the chassis level
Landing gear location: 2400mm behind the king pin
Tare weight (Tolerance 0-4%): approximate 7400kg
Payload: 30000kg
King Pin: φ50mm
Landing Gear: 2 speed road side winding with sand shoe, Lifting capacity 28T. Type: Fuwa.
Suspension: Mechanical suspension with 8 leaf spring(90mm width by 16mm thickness/leaf).
Axles: Fuwa square axle with 13 tons capacity.
Rims: 8.5-20 disc wheel, 9PCS; Supplier:Sunrise
Tires: 12R20 tyre, 9PCS; Supplier: Triangle
Brake System:Non ABS brake system
Brake Chamber: 30/30 type
Electric system: 24 volt lighting system with modular wiring harness, 7-pin socket
Business Card:
