SINOTRUK bulk cement trailer

                                            50 M3 BULK CEMENT SEMI TRAILER

DIMENSIONS

Tare weight

11000kg

Payload

40000 kg

Overall length

12000mm

Overall width

2500mm

Overall height

     4000mm

SPECIFICATION

Tank body

Q235A/5mm steel sheet                                            shape :V type

End plate

Q235A/6mm .ball shape

Axle

Number

       3

Brand

Fuwa

Capacity

13T

Suspension

Mechanical suspension or air suspension

Leaf spring

Leaf spring or air bag

Manhole cover

500mm manhole cover .3 sets

Tire

11.00R22.5

Discharge valve

4`disc valve

Dischage pipe

4`seamless steel tube

Kingpin

2` bolt-in king pin

Landing gear

 two-speed,manual operating ,heavy duty landing gear

Engine

Diesel engine or electrical motor

Air compressor

37 KW,0.2Mpa. 1000r/Min

Compartment

Single                                      inner fluidized bed:air bag

Braking system

WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks

Paiting

Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint

Accessories

One standard tool box

Air-charging system

2` main hole.2`check valve .1.5`safe valve.0.4Mpa.gauge

Quadratic blow

1`diameter check valve

Outlet discharge pipe

4`rubber hose .6m
