Electric-heated Annealing Lehr for Glasswares

Electric-heated Annealing Lehr for Glasswares thumbnail-1
Electric-heated Annealing Lehr for Glasswares photo-1
US$ 30,000 - 300,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Contact Supplier Request Quote Chat Now
Zhengzhou Dynnor Industrial Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Product Description

Our advantages:

We have a dedicated team in glass engineering sector with over 30 years of experience with various glass plants including refractory design,selection of equipments,melting furnace design &installation,maintenance,hot/cold repairs, rebuilds,heating-up and operation training, etc.. Our major expertise are involved with container glass,glassware, pattern glass and sheet glass. Either you have a flame-fired furnace(with or without electric boosting or bubbling system), electric furnace or oxygen-firing furnace, we can deliver the equipments in a total package or in part in the most efficient way.



Description of equipment:

this is the most advanced glassware annealing lehr equiped with hot air circulation system
main features: quick heating-up,high uniform of temperature distribution, no noise,no pollution
fully automatic controlled,subdivision control, automatic and precise adjust of temperature
Internal Circulation of the mesh belt,stepless variable speed or frequency conversion speed control.
excellent thermal insulation layer, equipments' outer faces kept at room temperature, high energy efficiency
tailor-made according to production capacity, length of annealing lehr adjustable to guarantee best performances in each different case.



Electric-heated glass annealing lehr
Srl.  Item Unit Main technical parameters
EAL EAL EAL EAL EAL EAL EAL EAL EAL EAL EAL EAL
BW600 BW900 BW1200 BW1500 BW1800 BW2100 BW2400 BW2700 BW3000 BW3300 BW3600 BW4200
1 Width of Mesh belt mm 600 900 1,200 1,500 1,800 2,100 2,400 2,700 3,000 3,300 3,600 4,200
2 Lever Height of  Mesh belt(B) mm 900-1,000(or Customized)
3 Mesh belt Speed  mm/ min 10-500
4 Maximum Temperature  ℃ 630
5 Temperature Difference at cross section ℃ +/- 2
6 chamber height mm 350/400
7 Max load of Mesh Belt  kg/m2 90
8 Thickness of Stainless Steel Container  mm 3
9 Gear Motor Power kw 1.1-3
10 Power of Circulation Fan  kw 1.1-2.2
11 Power of exhaust Heat Recovery Fan kw 0.75-1.5
12 electric heating capacity kw 180 240 336 420
13 Heating Wire 0Cr25AI5 or nickel chrome wire Cr20Ni80
14 Heating Method All-electric heating
15 Temperature Control Methods   full-automatic independent control
16 Full Length  mm 25,000-28,000
17 Width of High temperature section mm B+1,400
18 Width of cold section mm B+600
